Name: LGRIG® Drop Forged Wire Rope Clips LG450 US.Fed.Spec.
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

 LGRIG® Wire Rope Clip DIN741 Galvanized Malleable

 LGRIG® Malleable Wire Rope Clip DIN1142(EN13411-5)

 LGRIG® Malleable Wire Rope Clip LG-450 US Standard

 LGRIG® Drop Forged Wire Rope Clips LG450 US.Fed.Spec.

 LGRIG® Wire Rope & Cable Grip 0.5Ton 1Ton 2Ton 3Ton

 LGRIG® Simplex Wire Rope Grips Zinc Plated

 LGRIG® Duplex Wire Rope Clips/Grips Zinc plated

 LGRIG® Australian Standard Wire Rope Grips AS2076

 LGRIG® Closed Spelter Socket G-417 US Type

 LGRIG® Open Spelter Wire Rope Socket G-416 US Type

 LGRIG® Fist Grip Wire Rope Clips Hot Dip Galvanized

 LGRIG® Drop Forged Wire Rope Clips Italy Type

 LGRIG® Deka Wire Rope Clips Galvanized Malleable Cast Iron

 LGRIG® Drop Forged Wire Rope Clips G450 Stainless Steel US Type

 LGRIG® American Wire Rope Cable Grip

 LGRIG® Japanese Type Wire Rope Cable Grip

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Drop Forged Wire Rope Clips LG450 US.Fed.Spec.

Brand	LGRIG®
Standard	Meets or exceeds all requirements of ASME B30.26, FF-C-450 Type 1, Class 1
Material	Super Mild steel
Processing	Drop Forged
Finish	Electro-Galvanized, Hot Dip Galvanized, Powder Coated or Dacromet
Size	1/8”, 3/16′, 1/4”, 5/16”, 3/8”, 7/16”, 1/2”,9/16”, 5/8″, 3/4” 7/8”, 1″, 1-1/8”, 1-1/4”, 1-3/8”, 1-1/2”, 1-5/8”, 1-3/4”, 2”, 2-1/4”
Country of Origin	China

Specifications of LGRIG® Drop Forged Wire Rope Clips LG450 US.Fed.Spec.

Specifications of Drop Forged Wire Rope Clips G450 US.Fed.Spec.

Part No.	SIZE	DEMENSION						WEIGHT
		DEMENSION						/100PCS
		A	B	C	D	E	F	(KGS)
LGWRCUH01	1/8”	7/32	18	11	12	23	20	3
LGWRCUH02	3/16′	1/4”	24	14	15	29	23	5
LGWRCUH03	1/4”	5/16”	26	15	19	36	29	8.5
LGWRCUH04	5/16”	3/8”	35	19	22	43	33	13
LGWRCUH05	3/8”	7/16”	38	19	25	49	41	20
LGWRCUH06	7/16”	1/2”	47	25	30	57	46	32
LGWRCUH07	1/2”	9/16”	47	25	30	58	48	32
LGWRCUH08	9/16”	9/16”	57	32	33	63	52	44
LGWRCUH09	5/8″	9/16”	60	32	33	63	52	44
LGWRCUH10	3/4”	5/8”	70	36	38	72	56	63
LGWRCUH11	7/8”	3/4”	79	41	44	80	62	93
LGWRCUH12	1″	3/4”	89	45	48	88	66	110
LGWRCUH13	1-1/8”	3/4”	98	51	51	91	71	120
LGWRCUH14	1-1/4”	7/8”	108	56	59	105	80	170
LGWRCUH15	1-3/8”	7/8”	118	56	60	106	80	200
LGWRCUH16	1-1/2”	7/8”	125	60	66	113	87	220
LGWRCUH17	1-5/8”	1	135	66	70	120	92	330
LGWRCUH18	1-3/4”	1-1/8”	146	70	78	134	97	420
LGWRCUH19	2”	1-1/4”	161	75	85	147	111	610
LGWRCUH20	2-1/4”	1-1/4”						660
