Information of Stainless Steel Round O Ring-China LG™

Brand	LG RIGGING®
Material	Stainless Steel (AISI 304 / AISI 316)
Safety Factor	5: 1
Processing	Welded
Finish	Highly Polishing
Size	3mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm, 19mm

Specifications of Stainless Steel Round O Ring-China LG™


Part No.	A	L	WT	Part No.	A	L	WT
Part No.	mm	mm	kgs	Part No.	mm	mm	kgs
LGSSROR315	3	15	0.003	LGSSROR535	5	35	0.0189
LGSSROR320	3	20	0.0038	LGSSROR540	5	40	0.022
LGSSROR325	3	25	0.0048	LGSSROR545	5	45	0.0237
LGSSROR330	3	30	0.005	LGSSROR550	5	50	0.025
LGSSROR420	4	20	0.0074	LGSSROR625	6	25	0.02
LGSSROR425	4	25	0.0089	LGSSROR630	6	30	0.0244
LGSSROR430	4	30	0.0102	LGSSROR635	6	35	0.0279
LGSSROR435	4	35	0.012	LGSSROR640	6	40	0.031
LGSSROR440	4	40	0.013	LGSSROR645	6	45	0.035
LGSSROR525	5	25	0.0146	LGSSROR650	6	50	0.0384
LGSSROR630	6	30	0.016	LGSSROR655	6	55	0.042
Part No.	A	L	WT	Part No.	A	L	WT
Part No.	mm	mm	kgs	Part No.	mm	mm	kgs
LGSSROR660	6	60	0.045	LGSSROR1080	10	80	0.18
LGSSROR840	8	40	0.0587	LGSSROR10100	10	100	0.212
LGSSROR845	8	45	0.069	LGSSROR1260	12	60	0.193
LGSSROR850	8	50	0.077	LGSSROR1270	12	70	0.217
LGSSROR825	8	55	0.0814	LGSSROR1280	12	80	0.26
LGSSROR860	8	60	0.0814	LGSSROR12100	12	100	0.308
LGSSROR870	8	70	0.097	LGSSROR1475	14	75	0.331
LGSSROR880	8	80	0.106	LGSSROR1490	14	90	0.411
LGSSROR1050	10	50	0.108	LGSSROR1975	19	75	0.663
LGSSROR1060	10	60	0.136	LGSSROR1990	19	90	0.772
LGSSROR1070	10	70	0.151
