LGRIG®-stainless-steel-swage-toggle-jaw-terminal
LGRIG®-stainless-steel-swage-toggle-jaw-terminal
LGRIG®-stainless-steel-swage-toggle-jaw-terminal
LGRIG®-stainless-steel-swage-toggle-jaw-terminal
LGRIG®-stainless-steel-swage-toggle-fork-terminal
LGRIG®-stainless-steel-swage-toggle-fork-terminal
LGRIG®-stainless-steel-316-swage-toggle-terminal
LGRIG®-stainless-steel-316-swage-toggle-terminal
LGRIG®-stainless-steel-swage-toggle-jaw-terminal
LGRIG®-stainless-steel-swage-toggle-jaw-terminal
LGRIG®-stainless-steel-swage-toggle-fork-terminal
LGRIG®-stainless-steel-316-swage-toggle-terminal

LGRIG® Stainless Steel Swage Toggle Terminal

LGRIG® Stainless Steel Swage Toggle Terminal, also known as wire rope swage toggle jaw terminal.

Wire rope swage toggle jaw terminal is manufactured of high quality Stainless Steel 316.

Swage toggle terminal, for diagonal or angle installations and also to minimize the risk of fatigue due to sideway loads.

Swage Toggle Terminals are commonly used in shade structures, wire balustrade, architectural rigging, wire rope, marine, and general purpose applications.

Flexible fork end allows for Steel Wire Rope to be attached into the swage terminal and be used on angles.

Get A Quote
Products
Trawling Gear
Trawling Swivel
Hooks
Trawling Shackle
Rope Thimbles
Rings & Links
Kelly's Eye & Stoppers
G-Hooks & Recessed Links
Connectors
Tools
Rockhopper Spare Parts
Trawling Chain
Synthetic Rope
Trawl Wire
Anchors & Fittings
Wire Rope Clips
Ferrules & Terminals
Rigging Screws
Fishing Net Float
Fenders & Buoys
Lashing/Slings/Load Binders
Trawl Blocks & Pulley
Toggles & Spacers
Safety Appliance
Lifting & Rigging
G100 Products
G80 Products
Turnbuckles
Shackles
Eye Bolts & Nuts
Rigging Hooks
Swivels
Forged Rings & Connector
Quick Links
Snap Hooks
Wire Rope
Wire Rope Thimbles
Wire Ropes Clips & Grips
Wire Rope Sleeves/Ferrules
Chains & Accessories
Chain Binders
Ratchet Straps
Lifting Sling of Lifting & Rigging
Lever Hoist
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Eye Plate
Stainless Steel Products
Shade Sail Hardware
Stainless Shackles
Stainless Turnbuckle
Stainless Eye Bolts & Nuts
Stainless Thimbles
Stainless Rings
Stainless Swivels
Stainless Quick Link
Stainless Wire Clips
Stainless Hooks & Clips
Stainless Terminals
LGRIG® Stainless Steel Swage Jaw Terminal
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Stud Terminal
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Swage Toggle Terminal
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Stainless Steel Swage Machined Fork Terminal
Swageless Fittings Machined Fork Terminal Stainless Steel-China
Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China
Swageless Deck Toggle-LG RIGGING®
Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®
Swageless Lag Screw Terminal Stainless Steel-LG RIGGING®
Swageless Cable Fittings-Toggle Terminal-LG RIGGING®
Stainless U Bolts
Stainless Hinge
Stainless Pulleys
Drop Forged Stainless Products
Stainless Chains
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Latches
Mooring Compensators / Springs
Brake Lining
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture
Building Components
LGRIG® Lifting Clutch - Concrete Precast Element Lifting

Information of LGRIG® Stainless Steel Swage Toggle Terminal

Brand

LGRIG®

Standard

European Type

Material

Type 304 or Type 316 Stainless Steel

Processing

Stamping / machining

Finish

Highly Polishing

Size

3mm , 4mm , 5mm , 6mm , 8mm , 10mm

Country of Origin

China


Specifications of LGRIG® Stainless Steel Swage Toggle Terminal


Part No.

Wire


(mm)

A


(mm)

D


(mm)

H


(mm)

D1


(mm)

D2


(mm)

L1


(mm)

L


(mm)

KG/100

B.L.


(KG)

LGSSSTter03

3

7

6

15

3.3

6.35

38

75

3.5

1300

LGSSSTter04

4

10

8

20

4.3

7.5

45

89

6.5

2350

LGSSSTter05

5

12

9

25

5.3

9

51

104

11.8

3500

LGSSSTter06

6

13

12

30

6.4

12.6

64

127

27

4100

LGSSSTter08

8

17

16

40

8.4

16

76

163

37.5

6200

LGSSSTter10

10

20

19

45

10.5

18

89

184

64.5

9800


Bulk Photos of LGRIG® Stainless Steel Swage Toggle Terminal

LGRIG®-stainless-steel-swage-toggle-terminal-m12
LGRIG®-stainless-steel-swage-toggle-terminal-m16
We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86 19524345486
E-mail:
Add:
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
Request a Free Quote
Upload
or drag files here.

Related Stainless Terminals

Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®
Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®
LGRIG® Stainless Steel Swage Machined Fork Terminal
LGRIG® Stainless Steel Swage Machined Fork Terminal
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Jaw Terminal
LGRIG® Stainless Steel Swage Jaw Terminal
Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China
Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
China LG RIGGING's Updates
Exhibition in Norway 2024 LG RIGGING®
31
Jul
2025
Exhibition in Norway 2024 LG RIGGING® Learn More
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles
27
Jan
2025
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles Learn More
Introduction to Rigging Turnbuckles: Advantages and Applications
13
Jan
2025
Introduction to Rigging Turnbuckles: Advantages and Applications Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware Building Components
Resources
Video Blog FAQs About LG RIGGING® Document Download
About
Company News Industry News
Contact Us
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
sales@lg-lifting.com
+86 19524345486
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86 19524345486
