Name: Fishing Chain Grade 64 Hot Dip Galvanized Long/Mid/Short Link LG RIGGING®
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Trawling Swivel 

Hooks 

Trawling Shackle 

Rope Thimbles 

Rings & Links 

Kelly's Eye & Stoppers 

G-Hooks & Recessed Links 

Connectors 

Tools 

Rockhopper Spare Parts 

Trawling Chain 

 LGRIG® Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link

 LGRIG® Flyshoot Chain for Trawler

 Fishing Chain Grade 64 Hot Dip Galvanized Long/Mid/Short Link LG RIGGING®

 Trawling Chain DIN766 Stainless Steel Chain Short Link LG RIGGING®

 DIN764 Stainless Steel Chain Medium Link LG RIGGING®

 Stainless Steel Chain Long Link DIN763 LG RIGGING®

 Short Link Chain DIN 766 Trawling Chain LG RIGGING®

 Medium Link Chain DIN 764 Trawling Chain LG RIGGING®

 Long Link Chain DIN 763 Trawling Chain LG RIGGING®

 Calibrated Anchor Chain DIN 766 Trawling Chain LG RIGGING®

 DIN 5683 Long Link Chain Trawling Chain LG RIGGING®

 LGRIG® Grade 80 Alloy Lifting Chains Short Link EN818-2

 LGRIG® Grade 100 Alloy Lifting Chain Short Link EN818-2

 LGRIG® G80 Alloy Lifting Chain EN818-7

 Grade 70 Long Link Trailer Safety Chains NZS5467 Trawling Chain LG RIGGING®

Synthetic Rope 

Trawl Wire 

Anchors & Fittings 

Wire Rope Clips 

Ferrules & Terminals 

Rigging Screws 

Fishing Net Float 

Fenders & Buoys 

Lashing/Slings/Load Binders 

Trawl Blocks & Pulley 

Toggles & Spacers 

Safety Appliance 

Footrope Gear 

Trawl Door 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of Fishing Chain Grade 64 Hot Dip Galvanized Long/Mid/Short Link LG RIGGING®

Brand	LG RIGGING^®
Material	Super Alloy Steel
Grade	Grade 64
Processing	Welded
Finish	Hot Dip Galvanized
Size	Short link chain: 10mm, 13mm, 16mm, 19mm, 20mm Mid link chain: 13mm, 16mm, 19mm, 22mm, 26mm Long link chain: 9mm, 11mm, 13mm, 16mm, 19mm, 22mm, 28mm

Specifications of Fishing Chain Grade 64 Hot Dip Galvanized Long/Mid/Short Link LG RIGGING®

Part No.	Kinds of Chain	Dia. mm.	Inside length mm.	Inside width mm. min.	Outside width mm. max.	Kg /m	Proof force (kN)	Breaking Load (kN)
LGTCHDG10SL	Short Link Chain	10	30	14	36	2.2	44	101
LGTCHDG13SL		13	39	17	47.1	3.8	74	170
LGTCHDG16SL		16	48	22.4	57.4	5.63	112	257
LGTCHDG19SL		19	57	27.8	68.8	7.99	158	363
LGTCHDG20SL		20	60	29	72	8.85	175	402
LGTCHDG13ML	Mid Link Chain	13	52	19.5	48.5	3.36	74	170
LGTCHDG16ML		16	64	24	59	5.06	112	257
LGTCHDG19ML		19	76	28.5	69.5	7.15	158	363
LGTCHDG22ML		22	88	27	74	9.45	212	487
LGTCHDG26ML		26	92	31	86	13.63	296	680
LGTCHDG09LL	Long Link Chain	9	53	15	35	1.45	35	81
LGTCHDG11LL		11	63	18	43	2.16	53	122
LGTCHDG13LL		13	80	22	51	2.93	74	170
LGTCHDG16LL		16	100	26	61	4.42	112	257
LGTCHDG19LL		19	100	27	68	6.45	158	363
LGTCHDG22LL		22	120	32	84	8.75	212	487
LGTCHDG28LL		28	150	44	103	14.3	343	788

Caution:
Do Not Use for Overhead Lifting. DO NOT EXCEED THE WORKING LOAD LIMIT.

WORKING LOAD LIMIT designates the maximum stress in pounds which should ever be applied to chain. This refers also to chain in the best condition, when new, and when the load is applied uniformly to a straight, untwisted length of chain.

WARNING: WORK LOAD LIMIT MUST NOT BE EXCEEDED

BREAK TEST LOAD is the minimum load in pounds at which new chain has been found by experience to break, under tests in which the load is applied in direct tension to a straight length of chain with a uniform rate of speed on a standard chain testing machine.
