Name: LGRIG® Stainless Steel Hook and Eye Turnbuckle US Type
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Shade Sail Hardware 

Stainless Shackles 

Stainless Turnbuckle 

 LGRIG® Stainless Steel Eye to Eye Turnbuckle Commercial European Type

 LGRIG® Stainless Steel Commercial Turnbuckle Hook and Hook European Type

 LGRIG® Stainless Steel Hook Eye Turnbuckle European Type

 LGRIG® Jaw Jaw Turnbuckle Stainless Steel European Type

 LGRIG® Stainless Steel Rigging Screw Jaw & Jaw

 LGRIG® Stainless Steel Rigging Screw Jaw to Swage Stud

 LGRIG® Stainless Steel Rigging Screw Swage Stud & Swage Stud

 LGRIG® Stainless Steel Rigging Screw Body

 LGRIG® Stainless Steel Rigging Screw Toggle/Toggle

 LGRIG® Stainless Steel Rigging Screw Toggle/Swage Stud

 LGRIG® Stainless Steel Rigging Screw Machined Fork/Fork

 LGRIG® Stainless Steel Rigging Screw Machined Fork/Terminal

 LGRIG® Stainless Steel DIN 1480 Eye/Eye Turnbuckle

 LGRIG® Stainless Steel DIN 1480 Hook/Hook Turnbuckle

 LGRIG® Stainless Steel DIN 1480 Turnbuckle Eye/Hook

 LGRIG® Stainless Steel Turnbuckle Body US Type

 LGRIG® Eye & Eye Stainless Steel Turnbuckle

 LGRIG® Stainless Steel Hook and Eye Turnbuckle US Type

 LGRIG® Hook & Hook Stainless Steel Turnbuckle US Type

 LGRIG® Jaw & Eye Stainless Steel Turnbuckle US Type

 LGRIG® Jaw & Jaw Stainless Steel Turnbuckle US Type

 LGRIG® Eye to Hook Turnbuckle Stainless Steel JIS Standard

 LGRIG® Stainless Steel Turnbuckle Eye & Eye Korean Type

 LGRIG® Drop Forged Turnbuckle Stainless Steel US Type Body Only for Stainless Turnbuckle

 LGRIG® Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type for Stainless Turnbuckle

 LGRIG® Turnbuckle Drop Forged Stainless Steel Eye&Eye US Type for Stainless Turnbuckle

 LGRIG® Stainless Steel Drop Forged Jaw & Jaw Turnbuckle US Type for Stainless Turnbuckle

Stainless Eye Bolts & Nuts 

Stainless Thimbles 

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Stainless Steel Hook and Eye Turnbuckle US Type

Brand	LGRIG®
Standard	Turnbuckle conform to US Federal Specification (ASTM F1145-92 Type 1)
Material	Stainless steel (AISI 304/AISI 316)
Turnbuckle Type	Open Body Turnbuckle
End Fittings	Hook & Eye
Size	1/4×4", 5/16×4.5", 3/8×6", 1/2×6", 1/2×9", 1/2×12", 5/8×6", 5/8×9", 5/8×12” 3/4×6", 3/4×9", 3/4×12"
Processing	Cast / Forged
Finish	Highly Polishing
Tips	Corrosion Resistant
Country of Origin	China

Specifications of LGRIG® Stainless Steel Hook and Eye Turnbuckle US Type


Part No.	Size	L	L1	S	B	E
Part No.	in.
LGSSUSTEH1/4×4	1/4	4	7.43	0.37	0.32	0.78
LGSSUSTEH5/16×4.5	5/16	4.5	8.24	0.4	0.43	0.94
LGSSUSTEH3/8×6	3/8	6	10.63	0.48	0.51	1.12
LGSSUSTEH1/2×6	1/2	6	11.55	0.55	0.71	1.44
LGSSUSTEH1/2×9	1/2	9	14.55	0.55	0.71	1.44
LGSSUSTEH1/2×12	1/2	12	17.55	0.55	0.71	1.44
LGSSUSTEH5/8×6	5/8	6	12.77	0.74	0.87	1.75
LGSSUSTEH5/8×9	5/8	9	15.77	0.74	0.87	1.75
LGSSUSTEH5/8×12	5/8	12	18.77	0.74	0.87	1.75
LGSSUSTEH3/4×6	3/4	6	14.19	0.9	0.99	2.09
LGSSUSTEH3/4×9	3/4	9	17.19	0.9	0.99	2.09
LGSSUSTEH3/4×12	3/4	12	20.19	0.9	0.99	2.09
