swage dome head terminal stainless steel
swage terminal dome head stainless steel
swage terminal dome head stainless steel
dome head terminal stainless steel 316
dome head terminal stainless steel 316
dome head swage terminal stainless steel
dome head swage terminal stainless steel
swage dome head terminal stainless steel 316
swage dome head terminal stainless steel 316
dome head terminal stainless steel 304
dome head terminal stainless steel 304
LGRIG®-stainless-steel-dome-head-terminal
swage dome head terminal stainless steel
swage terminal dome head stainless steel
dome head terminal stainless steel 316
dome head swage terminal stainless steel
swage dome head terminal stainless steel 316
dome head terminal stainless steel 304

LGRIG® Stainless Steel Dome Head Terminal

LGRIG® Stainless Steel Dome Head Terminal, also known as Stainless Steel Swage Dome Head Terminal, designed for secure cable termination in stainless steel or timber post cable railing systems, ideal for hydraulically swaged balustrades, providing strong, vibration-resistant anchoring.

Swage dome head terminal, constructed from Grade 316 stainless steel for exceptional corrosion resistance.

Stainless steel cable railing dome head terminal, suitable for both interior and exterior applications, even in harsh environments.

Stainless steel wire rope dome head terminal, perfect for cable railings, balconies, staircases, decks, and architectural structures requiring reliable, long-lasting cable tension.

Stainless steel dome head crimp terminal, compatible with diverse materials (stainless steel, timber) and environments.

Guaranteed strength and all-weather performance for professional-grade installations.


Dome head design: Enables quick assembly in pre-drilled posts with compatible diameters.

Dual-end structure: Crimp end for cable attachment + flat dome head for clean, finished anchoring.


Installation of Wire rope dome head terminal:

Crimping required: Use a hydraulic swager to secure wire cables into the fitting.

Do NOT use hand tools (e.g., pliers/hand swagers) due to insufficient pressure for proper crimping.

Get A Quote
Products
Trawling Gear
Trawling Swivel
Hooks
Trawling Shackle
Rope Thimbles
Rings & Links
Kelly's Eye & Stoppers
G-Hooks & Recessed Links
Connectors
Tools
Rockhopper Spare Parts
Trawling Chain
Synthetic Rope
Trawl Wire
Anchors & Fittings
Wire Rope Clips
Ferrules & Terminals
Rigging Screws
Fishing Net Float
Fenders & Buoys
Lashing/Slings/Load Binders
Trawl Blocks & Pulley
Toggles & Spacers
Safety Appliance
Lifting & Rigging
G100 Products
G80 Products
Turnbuckles
Shackles
Eye Bolts & Nuts
Rigging Hooks
Swivels
Forged Rings & Connector
Quick Links
Snap Hooks
Wire Rope
Wire Rope Thimbles
Wire Ropes Clips & Grips
Wire Rope Sleeves/Ferrules
Chains & Accessories
Chain Binders
Ratchet Straps
Lifting Sling of Lifting & Rigging
Lever Hoist
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Eye Plate
Stainless Steel Products
Shade Sail Hardware
Stainless Shackles
Stainless Turnbuckle
Stainless Eye Bolts & Nuts
Stainless Thimbles
Stainless Rings
Stainless Swivels
Stainless Quick Link
Stainless Wire Clips
Stainless Hooks & Clips
Stainless Terminals
LGRIG® Stainless Steel Swage Jaw Terminal
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Stud Terminal
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Swage Toggle Terminal
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Stainless Steel Swage Machined Fork Terminal
Swageless Fittings Machined Fork Terminal Stainless Steel-China
Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China
Swageless Deck Toggle-LG RIGGING®
Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®
Swageless Lag Screw Terminal Stainless Steel-LG RIGGING®
Swageless Cable Fittings-Toggle Terminal-LG RIGGING®
Stainless U Bolts
Stainless Hinge
Stainless Pulleys
Drop Forged Stainless Products
Stainless Chains
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Latches
Mooring Compensators / Springs
Brake Lining
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture
Building Components
LGRIG® Lifting Clutch - Concrete Precast Element Lifting

Information of LGRIG® Stainless Steel Dome Head Terminal

Brand

LGRIG®

Standard

European Type

Material

Type 304 or Type 316 Stainless Steel

Processing

Machining

Finish

Highly Polishing

Size - Wire

3mm , 4mm , 5mm , 6mm , 8mm , 10mm

Tips

These Fittings need to be Hydraulically Crimped or Swaged onto the Steel Wire Rope

Country of Origin

China


Specifications of LGRIG® Stainless Steel Dome Head Terminal


Part No.

Wire

(mm)

L1

(mm)

L2

(mm)

L3

(mm)

D2

(mm)

D3

(mm)

W/100

(KGS)

LGSSTERDH03

3

35

25

32

5.5

8

0.5

LGSSTERDH04

4

35

25

32

6.35

10

0.7

LGSSTERDH05

5

41

30

47

7.5

11.5

1.0

LGSSTERDH06

6

52

40

47

9

14

1.9

LGSSTERDH08

8

66

50

60

12.58

18

5.0

LGSSTERDH10

10

77

60

70

16

22

9.2



We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86 19524345486
E-mail:
Add:
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
Request a Free Quote
Upload
or drag files here.

Related Stainless Terminals

LGRIG® Stainless Steel Swage Machined Fork Terminal
LGRIG® Stainless Steel Swage Machined Fork Terminal
Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®
Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
Swageless Fittings Machined Fork Terminal Stainless Steel-China
Swageless Fittings Machined Fork Terminal Stainless Steel-China
Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China
Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China
LGRIG® Stainless Steel Swage Stud Terminal
LGRIG® Stainless Steel Swage Stud Terminal
Swageless Deck Toggle-LG RIGGING®
Swageless Deck Toggle-LG RIGGING®
China LG RIGGING's Updates
Exhibition in Norway 2024 LG RIGGING®
31
Jul
2025
Exhibition in Norway 2024 LG RIGGING® Learn More
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles
27
Jan
2025
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles Learn More
Introduction to Rigging Turnbuckles: Advantages and Applications
13
Jan
2025
Introduction to Rigging Turnbuckles: Advantages and Applications Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware Building Components
Resources
Video Blog FAQs About LG RIGGING® Document Download
About
Company News Industry News
Contact Us
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
sales@lg-lifting.com
+86 19524345486
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86 19524345486
