Information of LGRIG® Stainless Steel Lifting Chain

Brand	LGRIG®
Material	Type 304 or Type 316 Stainless Steel
Processing	Welded
Finish	Highly Polished
Size	3/16”, 9/32”, 5/16”, 3/8”, 1/2”
Tips	Perfect for use in exterior and corrosive environments
Country of Origin	China

Specifications of LGRIG® Stainless Steel Lifting Chain

Part No.	SIZE	A	B	C	WLL	BL	WT
LGSSLC101	3/16″	0.19″	0.58″	0.25″	1,100	4,400	0.36
LGSSLC102	9/32″	0.28″	0.85″	0.38″	2,200	8,800	0.97
LGSSLC103	5/16″	0.32″	0.95″	0.45″	2,700	10,800	0.98
LGSSLC104	3/8″	0.39″	1.18″	0.55″	4,400	17,600	1.41
LGSSLC105	1/2″	0.51″	1.55″	0.75″	7,300	29,200	2.6

Never exceed the working load limit.
Working loads are based on gradual pull and not shock loads.
Make sure that all components in your assembly are overhead lifting rated and have the same working loads.

Please note we supply a huge variety of stainless steel parts.

Both stainless steel chains and carbon/alloy chains are available.
