Name: LGRIG® Stainless Steel Swage Machined Fork Terminal
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Shade Sail Hardware 

Stainless Shackles 

Stainless Turnbuckle 

Stainless Eye Bolts & Nuts 

Stainless Thimbles 

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

 LGRIG® Stainless Steel Swage Jaw Terminal

 LGRIG® Stainless Steel Swage Eye Terminal

 LGRIG® Stainless Steel Swage Stud Terminal

 LGRIG® Stainless Steel Dome Head Terminal

 LGRIG® Stainless Steel Swage Toggle Terminal

 LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing

 LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)

 LGRIG® Stainless Steel Swage Machined Fork Terminal

 Swageless Fittings Machined Fork Terminal Stainless Steel-China

 Swageless Eye Terminal Stainless Steel Cable Railing Hardware-China

 Swageless Deck Toggle-LG RIGGING®

 Swageless Thread Stud Terminal Stainless Steel-LG RIGGING®

 Swageless Lag Screw Terminal Stainless Steel-LG RIGGING®

 Swageless Cable Fittings-Toggle Terminal-LG RIGGING®

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Stainless Steel Swage Machined Fork Terminal

Brand	LGRIG®
Material	Type 304 or Type 316 Stainless Steel
Processing	Machining
Finish	Highly Polishing
Size - Wire	3mm , 4mm , 5mm , 6mm , 8mm , 10mm
Tips	These Fittings need to be Hydraulically Crimped or Swaged onto the Steel Wire Rope
Country of Origin	China

Specifications of LGRIG® Stainless Steel Swage Machined Fork Terminal


Part No.	Wire (mm)	A (mm)	D (mm)	H (mm)	D1 (mm)	D2 (mm)	L1 (mm)	L (mm)	KG/100	B.L. (KG)
LG-SS-SMFter-03	3	7.5	6	10	3.3	6.5	39	73	4	1300
LG-SS-SMFter-04	4	11	8	11	4.3	7.5	45	86	7.3	2350
LG-SS-SMFter-05	5	12	9	14	5.3	9	52	100	11	2350
LG-SS-SMFter-06	6	14	12	20	6.4	12.5	64	128	23	4700
LG-SS-SMFter-07	7	15	12	22	7.4	14.2	70	135	32	5100
LG-SS-SMFter-08	8	17	16	26	8.4	16	80	155	50	7600
LG-SS-SMFter-10	10	20	19	30	10.5	18	90	174	92	9800
LG-SS-SMFter-12	12	20	19	30	12.6	20	105	197	100	13000
LG-SS-SMFter-14	14	22	22	35	14.7	25	140	239	170	17000
LG-SS-SMFter-16	16	25	25	38	16.9	28	160	271	210	24000
LG-SS-SMFter-19	19	30	28	41	20	34.5	200	327	330	27000
LG-SS-SMFter-22	22	35	32	52	23.2	40.5	230	377	480	31000
LG-SS-SMFter-26	26	35	35	52	27.5	46	280	434	700	43000
