Information of LGRIG® Stainless Steel Swing Eye Bolt UNC Thread

Brand	LGRIG®
Material	Stainless steel Type 304 / 316 Swing Eye Bolt
Processing	Forged
Finish	High polished
Size	5/16", 3/8", 1/2", 5/8", 3/4" swing eye bolt
Tip	Other sizes and custom lengths on request.
Application	Swing bolts on food storage and processing equipment. Chemical processing plants. Securing lids on centrifuge equipment.
Country of Origin	China

Specifications of Stainless Steel Swing Eye Bolt UNC Thread

Part No.	A	B	C	D
LG-SS-SEB-F-01	5/16”	4.25”	7/8”	5/16”
LG-SS-SEB-F-02	5/16”	5”	7/8”	5/16”
LG-SS-SEB-F-03	3/8”	4.30”	1-1/8”	3/8”
LG-SS-SEB-F-04	3/8”	5”	1-1/8”	3/8”
LG-SS-SEB-F-05	3/8”	1.92”	1-1/8”	3/8”
LG-SS-SEB-F-06	3/8”	2.68”	1-1/8”	3/8”
LG-SS-SEB-F-07	3/8”	3.56”	1-1/8”	3/8”
LG-SS-SEB-F-08	1/2”	4.36”	1-1/4”	1/2”
LG-SS-SEB-F-09	1/2”	5.12”	1-1/4”	1/2”
LG-SS-SEB-F-10	1/2”	6”	1-1/4”	1/2”
LG-SS-SEB-F-11	1/2”	3”	1-1/4”	1/2”
LG-SS-SEB-F-12	1/2”	3.62”	1-1/4”	1/2”
LG-SS-SEB-F-13	5/8”	4.50”	1-1/2”	1/2”
LG-SS-SEB-F-14	5/8”	5.30”	1-1/2”	5/8”
LG-SS-SEB-F-15	5/8”	6.20”	1-1/2”	5/8”
LG-SS-SEB-F-16	5/8”	2.95”	1-1/2”	5/8”
LG-SS-SEB-F-17	5/8”	3.78”	1-1/2”	5/8”
LG-SS-SEB-F-18	3/4”	3.92”	1-3/4”	3/4”
LG-SS-SEB-F-19	3/4”	4.65”	1-3/4”	3/4”
LG-SS-SEB-F-20	3/4”	5.38”	1-3/4”	3/4”
LG-SS-SEB-F-21	3/4”	6.20”	1-3/4”	3/4”
LG-SS-SEB-F-22	3/4”	3”	1-3/4”	3/4”
