Name: LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector US Type
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Shade Sail Hardware 

Stainless Shackles 

Stainless Turnbuckle 

Stainless Eye Bolts & Nuts 

Stainless Thimbles 

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

 Stainless Steel Drop Forged Lifting Eye Bolt DIN 580

 Lifting Eye Nut DIN 582 Drop Forged Stainless Steel

 Stainless Steel Drop Forged Shoulder Eye Bolt With Collar

 LGRIG® Turnbuckle Body Only Drop Forged Stainless Steel US Type

 LGRIG® Drop Forged Stainless Steel Jaw & Eye Turnbuckle US Type

 LGRIG® Drop Forged Stainless Steel Eye & Eye Turnbuckle US Type

 LGRIG® Drop Forged Stainless Steel Jaw & Jaw Turnbuckle US Type

 LGRIG® Drop Forged Wire Rope Clips G450 Stainless Steel US Type

 Stainless Steel Drop Forged Anchor Shackle Oversized Screw Pin G-209

 Stainless Steel Forged Chain Shackle Oversized Screw Pin-LG RIGGING®

 Stainless Steel Drop Forged Bow Shackle Oversized Bolt Type Pin

 Forged D Shackle Oversized Bolt Type Pin Stainless Steel G-2150

 Stainless Steel Drop Forged Weld-on D Ring-LG RIGGING®

 LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector European Type

 LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector US Type

 LGRIG® Stainless Steel Drop Forged Master Link

 Stainless Steel Drop Forged Split Chain Connecting Link

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector US Type

Brand	LGRIG®
Standard	Hammerlock chain connector meet US Federal Specification
Material	Stainless steel Type 304 or 316 Connecting Link
Processing	Drop Forged
Finish	Polishing
Size	1/4", 5/16", 3/8", 1/2", 5/8", 3/4",7/8", 1", 1-1/4"
Country of Origin	China

Specifications of LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector US Type


Part No.	WEIGHT /lbs	WORKING LOAD LIMIT /lbs	BREAKING LOAD /lbs	A±1.5	L±2.5	K±2	W±l	H±1	C±0.2	D±0.3
LGDFSSCLUS1/4	0.286	3500	14000	16.5	67	51	8	13	4	4
LGDFSSCLUS5/16	0.32	4500	18000	17	78.5	58.5	10	14.5	6	6.6
LGDFSSCLUS3/8	0.73	7100	28400	22	87.6	63.6	12	17	6.2	8.1
LGDFSSCLUS1/2	1.67	12000	48000	28.5	115.5	85.5	15	21.6	7.8	7.8
LGDFSSCLUS5/8	2.86	18100	72400	33	143	106	18.5	26	9.5	10
LGDFSSCLUS3/4	5	28300	113200	41	162	116	23	32	12	13
LGDFSSCLUS7/8	7.5	34200	136800	50.5	188.5	136.5	26	38	13	15.5
LGDFSSCLUS1	11.03	47700	190800	57	214.5	152.5	31	44	15	16.5
LGDFSSCLUS1/4	20.38	72300	289200	65	265	188.7	38	54	20	20
