 LGRIG® Jaw & Jaw Stainless Steel Turnbuckle US Type

 LGRIG® Eye to Hook Turnbuckle Stainless Steel JIS Standard

 LGRIG® Stainless Steel Turnbuckle Eye & Eye Korean Type

 LGRIG® Drop Forged Turnbuckle Stainless Steel US Type Body Only for Stainless Turnbuckle

 LGRIG® Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type for Stainless Turnbuckle

 LGRIG® Turnbuckle Drop Forged Stainless Steel Eye&Eye US Type for Stainless Turnbuckle

 LGRIG® Stainless Steel Drop Forged Jaw & Jaw Turnbuckle US Type for Stainless Turnbuckle

Stainless Eye Bolts & Nuts 

Stainless Thimbles 

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Eye & Eye Stainless Steel Turnbuckle

LGRIG® Eye & Eye Stainless Steel Turnbuckle US Type, also known as Turnbuckle Eye & Eye Stainless Steel.

Stainless Steel Eye and Eye Turnbuckle US Type, Crafted from durable Type 316 stainless steel, this eye-and-eye turnbuckle provides excellent corrosion resistance and reliable performance in tensioning applications such as wire hung canopies, shade sails, boat lifelines, and other structural rigging.

Its closed-eye design makes it ideal for setups that do not require frequent disassembly, while the drop forged, elongated eyes offer added strength and easier hook up.

Complying with ASTM F1145-92 Type 1, Class H specifications, the hex-body turnbuckle is manufactured in the style of hot dipped galvanized turnbuckles but with the superior material benefits of stainless steel.

For optimal performance and to prevent thread galling, applying a high quality anti-seize lubricant during installation is recommended.

Note: The working load limit must never be exceeded, and it is the user's responsibility to ensure the finished structure complies with all applicable local building codes and that appropriate hardware is selected for the intended use.

Specifications of LGRIG® Eye & Eye Stainless Steel Turnbuckle

Part No.	Size	L	L1	B	E	D2
Part No.	in.
LGSSUSTEE1/4×4	1/4	4	8	0.32	0.78	0.24
LGSSUSTEE5/16×4.5	5/16	4.5	8.6	0.43	0.94	0.3
LGSSUSTEE3/8×6	3/8	6	10.94	0.51	1.12	0.35
LGSSUSTEE1/2×6	1/2	6	12	0.71	1.44	0.45
LGSSUSTEE1/2×9	1/2	9	15	0.71	1.44	0.45
LGSSUSTEE1/2×12	1/2	12	18	0.71	1.44	0.45
LGSSUSTEE5/8×6	5/8	6	13.8	0.87	1.75	0.51
LGSSUSTEE5/8×9	5/8	9	16.8	0.87	1.75	0.51
LGSSUSTEE5/8×12	5/8	12	19.8	0.87	1.75	0.51
LGSSUSTEE3/4×6	3/4	6	15.38	0.99	2.09	0.67
LGSSUSTEE3/4×9	3/4	9	18.38	0.99	2.09	0.67
LGSSUSTEE3/4×12	3/4	12	21.38	0.99	2.09	0.67
LGSSUSTEE7/8×6	7/8	6	16.5	1.21	2.38	0.75
LGSSUSTEE7/8×12	7/8	12	22.5	1.21	2.38	0.75
LGSSUSTEE1×6	1	6	18.8	1.37	3	0.91
LGSSUSTEE1×12	1	12	24.8	1.37	3	0.91
LGSSUSTEE1-1/4×12	1-1/4	12	26.5	1.37	3.56	1.14
