G80 Eye Self-locking Hook Dacromet

G80 Eye Self-Locking Hook Dacromet allows the hook to remain open until the engage the load. The hook will not open until the trigger at the back is pressed.

G80 safety hook eye type, forged by special alloy steel with high intensity and high toughness, and then heat treated.

The surface finish of this G80 eye self-locking hook is Dacromet.

It can be matched with sling and G80 chains which can meet the standard EN818-2.

The eye style allows easy connection to Chain Connectors, Shackles and Wire Rope Slings.

Trawling Gear
Shackles
Boat Fittings

Informations of G80 Eye Self-Locking Hook Dacromet

Technical Notes

G80 Eye Self-Locking Hook conform to European Type

Material

Superior Alloy Steel.

Safety Factor

4: 1

Processing

Forged / Quenched and Tempered.

Finish

Dacromet

Size

6mm, 7/8mm, 10mm, 13mm, 16mm, 18/20mm, 22mm, 26mm, 32mm

Tips

Color Code: Customized according to customers’ requirements

Note

Use Only Grade 80 Attachments For Overhead Lifting


Specifications of G80 Eye Self-Locking Hook Dacromet


Item No.

Weight (kg)

Woring Load Limit (t)

Breaking Load (t)

Φ±1

E±2

E1±2

L1±3

L±3

8-LG-DESLH-6

0.5

1.12

4.48

21

35

28

110

141

8-LG-DESLH-7/8

0.88

2

8

25

40

35

136

175

8-LG-DESLH-10

1.58

3.15

12.6

34.5

50

45

168

214

8-LG-DESLH-13

3.0

5.3

21.2

40

60

52.5

207

268

8-LG-DESLH-16

5.9

8

32

50

65

63.3

254

332

8-LG-DESLH-18/20

7.0

12.5

50

64.5

80

86

274.5

332

8-LG-DESLH-22

12.3

15

60

70

83

76

319

415

8-LG-DESLH-26

20

21.2

84.8

80

106

96

362

472

8-LG-DESLH-32

44

31.5

126

105

140

133

470

614
