Information of LGRIG® Eye Hoist Hook with Latch LG320A Grade 70

Brand	LGRIG®
Grade	Grade 70
Model	L-320A
Standard	Eye Hoist Hook with Latch conform to U.S. Federal Specification
Material	Super Alloy Steel
Safety Factor	5: 1
Processing	Body : Drop Forged / Quenched and Tempered Latch: Stamping
Finish	Body: Powder Coated / Hot Dip Galvanized / Zinc Plated / Self-Colored Latch: Dacromet / Zinc Plated
WLL	0.75Ton, 1Ton, 1.5Ton, 2Ton, 3Ton, 5Ton, 7Ton, 11Ton, 15Ton, 22Ton, 30Ton
Tips	Finish: Customized according to customers‘ requirements
Country of Origin	China

Specifications of LGRIG® Eye Hoist Hook with Latch LG320A Grade 70


Part No.	Weight (KG)	Alloy Steel		D±0.6	E±2	H±1.5	K±2.5	M±5	L±3
Part No.	Weight (KG)	WLL(t)	B.L.(t)	D±0.6	E±2	H±1.5	K±2.5	M±5	L±3
LG320AEH01	0.21	0.75	3.75	16.5	19	17	72	16	97
LG320AEH02	0.28	1	5	19	22	19	82	16	110
LG320AEH03	0.4	1.5	7.5	23	23	21	93.5	17.5	125
LG320AEH04	0.65	2	10	28	24	26	103	21	140.5
LG320AEH05	0.81	3	15	31	27.5	28	119	23	162
LG320AEH06	1.75	5	25	39	33	37	146	30	201
LG320AEH07	3.77	7	35	51	40	46.5	186.5	38	256
LG320AEH08	6.8	11	55	62	51	57	231.5	46	317
LG320AEH09	9.96	15	75	73	57	70	260	55	360
LG320AEH10	15.33	22	110	89	75	76	318	68.5	434
LG320AEH11	27.2	30	150	90	82	91	360	70	495.5
