Information of LGRIG® Eye Hoist Hook with Latch LG320C Grade 43 High Test

Brand	LGRIG®
Grade	Grade 43
Model	L-320C
Standard	Eye Hoist Hook with Latch conform to U.S. Federal Specification
Material	Super Carbon Steel
Safety Factor	5: 1
Processing	Body: Drop Forged / Quenched and Tempered Latch: Stamping
Finish	Body: Powder Coated / Hot Dip Galvanized / Zinc Plated / Self-Colored Latch: Dacromet / Zinc Plated
WLL	0.5Ton, 0.75Ton, 1Ton, 1.5Ton, 2Ton, 3Ton, 5Ton, 7.5Ton, 10Ton, 15Ton, 20Ton
Tips	Finish: Customized according to customers’ requirements
Country of Origin	China

Specification of LGRIG® Eye Hoist Hook with Latch LG320C Grade 43 High Test


Part No.	Weight (KG)	Carbon steel		D±0.6 (mm)	E±2 (mm)	H±1.5 (mm)	K±2.5 (mm)	M±5 (mm)	L±3 (mm)
Part No.	Weight (KG)	WLL(t)	B.L.(t)	D±0.6 (mm)	E±2 (mm)	H±1.5 (mm)	K±2.5 (mm)	M±5 (mm)	L±3 (mm)
LG320CEH01	0.21	0.5	2.5	16.5	19	17	72	16	97
LG320CEH02	0.28	0.75	3.75	19	22	19	82	16	110
LG320CEH03	0.4	1	5	23	23	21	93.5	17.5	125
LG320CEH04	0.65	1.5	7.5	28	24	26	103	21	140.5
LG320CEH05	0.81	2	10	31	27.5	28	119	23	162
LG320CEH06	1.75	3	15	39	33	37	146	30	201
LG320CEH07	3.77	5	25	51	40	46.5	186.5	38	256
LG320CEH08	6.8	7.5	37.5	62	51	57	231.5	46	317
LG320CEH09	9.96	10	50	73	57	70	260	55	360
LG320CEH10	15.33	15	75	89	75	76	318	68.5	434
LG320CEH11	27.2	20	100	90	82	91	360	70	495.5
