Name: LGRIG® Forged Screw Eye Bolts LG-275
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

 LGRIG® Collared Eyebolt BS 4278 Table 1 Metric

 LGRIG® Fork Head Clevis Joint DIN71752

 LGRIG® DIN580 Eye Bolt Galvanized

 LGRIG® DIN 582 Lifting Eye Nut

 LGRIG® Bow Nuts B.S. 3974 Metric Coarse & BSW Thread

 LGRIG® Long Shank Metric Collared Eye bolt BS4278 Table-1

 LGRIG® Collared Eyebolt With Oval Link Metric BS 4278 Table 2

 LGRIG® Dynamo Eyebolt with Enlarged Eye BS 4278 Table 3 Metric

 LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

 LGRIG® JIS 1168 Eye Bolt Forged Galvanized Carbon Steel

 LGRIG® JIS B 1169 Forged Eye Nut

 LGRIG® Forged Shoulder Machinery Eye Bolt LGS-279/LGM-279

 LGRIG® Forged Screw Eye Bolts LG-275

 LGRIG® Forged Shoulder Nut Eye Bolts LG-277

 LGRIG® Regular Nut Eye Bolts LG-291

 LGRIG® G-400 Eye Nut Galvanized UNC Threaded

 LGRIG® Rectangular Base Deck Eye Plates

 LGRIG® DIN 444 Swing Eye Bolt

 LGRIG® Wood Lag Screw w/Ring Thread Ring Bolt

 LGRIG® Welded Eye Bolt Wire Turned with Lock nut

 LGRIG® Unwelded Eye Bolt Wire Turned

 LGRIG® Lag Screw Eye Bolts Welded

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Forged Screw Eye Bolts LG-275

Brand	LGRIG®
Standard	Eye bolt meets or exceeds all requirements of ASME B30.26.
Model	G-275
Processing	Forged, Quenched & Tempered
Finish	Hot Dip Galvanized
Tips	Working Load Limits shown are for in-line pull.
Country of Origin	China

Specifications of LGRIG® Forged Screw Eye Bolts LG-275


Part No.	Size	Dimensions (in.)									Weight (lbs)
Part No.	Size	A	B	C	D	E	F	G	H	J	Weight (lbs)
LG275EB101	1/4 × 2″	0.25	1.5	2	2.5	2.94	0.5	0.88	0.19	0.47	0.05
LG275EB102	5/16 × 2-1/4″	0.31	1.69	2.25	2.94	3.5	0.63	1.13	0.25	0.56	0.1
LG275EB103	3/8 × 2-1/2″	0.38	1.88	2.5	3.28	3.97	0.75	1.38	0.31	0.66	0.19
LG275EB104	1/2 × 3-1/4″	0.5	2.44	3.25	4.25	5.12	1	1.75	0.38	0.91	0.38
LG275EB105	5/8 × 4″	0.63	3	4	5.31	6.44	1.25	2.25	0.5	1.12	0.86
LG275EB106	3/4 x 4-1/2″	0.75	3.5	4.5	6.25	7.44	1.5	2.75	0.62	1.38	1.38
