 LGRIG® B.S.3032 Small Bow Shackle with Screw Collar Pin

 LGRIG® BS3032 Small Dee Shackle with Type A Screw Collar Pin

 LGRIG® B.S.3032 Large Bow Shackle with Screw Collar Pin

 LGRIG® BS3032 Large Dee Shackle with Type A Screw Collar Pin

 LGRIG® Shackles Similar to Din 82101 Form A/B/C Galvanised

 LGRIG® Italy Type Galvanized Bow Shackle Screw Pin

 LGRIG® Galvanized Dee Shackles Italy Type

 LGRIG® Round Pin Anchor Shackle U.S. Type

 LGRIG® Round Pin Chain Shackle US Type

 LGRIG® Piling Shackle Long D Shackle

 Trawling Shackle D Type Blue Painted Square Head Pin of Lifting & Rigging Shackles

 Trawling Shackle Bow Type Square Head Pin Blue Painted of Lifting & Rigging Shackles

 Bow Shackle Square Head Pin High Tensile of Lifting & Rigging Shackles

 Dee Shackle Square Head Pin for Lifting and Rigging Shackles

 Bow Shackle Sunken Head of Lifting & Rigging Shackles

 Dee Shackle Sunken Head of Lifting & Rigging Shackles

 LGRIG® G80 Unilock Shackle Connecting Link

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Informations of G80 Unilock Shackle Connecting Link LG RIGGING®

Brand	LGRIG®
Grade	Grade 80
Standard	BS EN1677-1
Material	Super Alloy Steel
Processing	Forged, Quenched and tempered
Finish	Powder Coated, Galvanized
Size	6mm, 8mm, 10mm, 13mm
Safety Factor	4:1
Packing	Cartons and then on Pallets (customization are available)

Specifications of G80 Unilock Shackle Connecting Link LG RIGGING®

Part No.	WEIGHT /KG	WLL/T	B.L/T	A±2	B±2	C±1	D±2	E±2	F±2	L±3	∅±0.5	∅±0.5	K±2
8LGSULOC6	0.1	1.12	4.48	11	24	17	21	34	39	56	9	7.6	7.8
8LGSULOC8	0.22	2	8	16.5	32	22	27.5	48.5	55.5	78.3	14	10	12.5
8LGSULOC10	0.38	3.15	12.6	20	38	28	35	58	67	95.5	16	12	15
8LGSULOC13	0.63	5.3	21.2	24.5	45	34.5	39	69.5	75	113.5	18	16	18.5
