Name: Grade 70 Transport Chain Binder Chain US Fed. Spec.
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

 Grade 100 Alloy Lifting Chain EN818-2 of Chains and Accessories

 Grade 80 Alloy Lifting Chains EN818-2 of Chains and Accessories

 G80 Alloy Lifting Chain EN818-7 of Chains and Accessories

 Fishing Link Chain G80 Alloy Steel of Chains and Accessories

 Grade 70 Transport Chain Binder Chain US Fed. Spec.

 DIN 763 Long Link Chain

 DIN 764 Medium Link Chain

 DIN 766 Short Link Chain

 Calibrated Anchor Chain DIN 766

 Calibrated Anchor Chain DIN 766 Stainless Steel

 DIN 5685 A/C Short/Long Link Chain

 DIN 5683 Long Link Chain-LG RIGGING®

 Australian Standard Grade 70 Chain

 Austrilian Standard Short Link Chain

 Regular Link Proof Coil Chain Australian Standard

 Long Link Proof Coil Chain Australian Standard

 Grade L Lifting Chain G30 Galvanised

 Long Link Trailer Safety Chains NZS5467 G70

 Studless Link Anchor Chain Common Link

 Grade U1 U2 U3 Stud Link Anchor Chain Common Link

 Grade 70 Chain Anchor with Delta Ring and Grab Hook

 Grab Hook w/ 18'' Chain Anchor Pear Ring

 Trailer Safety Chain with 2 ''S'' Hooks Grade 30

 G43/ G70 Chain With Clevis Hooks/Eye Hooks

 Straight Link Coil Chain, Zinc Plated

 Twist Link Coil Chain, Zinc Plated

 Double Loop Weldless Chain

 Sash Chains, Weldless Chain

 Cold Shut Chain Links

 Zinc Plated Chain Lap / Repair Link, Mending Link

 Clevis Lug Links Grade 70 Australia Standard

 Split Connecting Links, Chain Connecting Links, G-335 Missing Link

 Grade 43 High Test Chain, Towing Chain

 Twin Clevis Link of Chains and Accessories

 Double Clevis Link Forged Steel of Chains and Accessories

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of Grade 70 Transport Chain Binder Chain US Fed. Spec.

Technical Notes	G70 transport chain Conform to NACM96
Material	High-strength, Alloy steel
Processing	Welded
Finish	Yellow Passivated
Size	1/4″, 5/16″, 3/8″, 7/16″, 1/2″, 5/8″, 3/4″
Safety Factor	4:1

Specifications of Grade 70 Transport Chain Binder Chain US Fed. Spec.

Part No.	Nominal Chain Size		Material Diameter		Working Load Limit (MAX.)		Proof Test (Min.)		Breaking Force (Min.)		Inside Length (Max.)		Inside Width (Max.)		Weight Kgs/100FT
Part No.	INCH	MM	INCH	MM	LBS	KG	LBS	KN	LBS	KN	INCH	MM	INCH	MM	Weight Kgs/100FT
LGWC2001	1/4”	7	0.281	7	3150	1430	6300	28	12600	56	1.24	31.5	0.38	9.8	28.12
LGWC2002	5/16”	8.7	0.343	8.7	4700	2130	9400	41.8	18800	83.6	1.29	32.8	0.44	11.2	45.84
LGWC2003	3/8”	10	0.406	10.3	6600	2990	13200	58.7	26400	117.4	1.38	35	0.55	14	67.41
LGWC2004	7/16”	11.9	0.468	11.9	8750	3970	17500	77.8	35000	155.4	1.64	41.6	0.65	16.6	89.26
LGWC2005	1/2”	13	0.531	13.5	11300	5130	22600	100.4	45200	200.8	1.79	45.5	0.72	18.2	116.06
LGWC2006	5/8”	16	0.63	16	15800	7170	31600	140.4	63200	280.8	2.2	56	0.79	20	159.01
LGWC2007	3/4”	20	0.787	20	24700	11200	49400	219.6	98800	439.2	2.76	70	0.98	25	248.46
