Heavy Duty Wire Rope Thimble K2-B LG RIGGING®, conform to type K2-B, aka type K2-B reinforced thimble with gussett, made of superior mild steel.

Heavy Duty Stub-End Wire Rope Thimble K2-B offer superior resistance to corrosive elements over standard zinc-plated components so they'll ideal for outdoor applications such as guy wire, tensioning, and other critical, heavy duty jobs.

While zinc-plating offers light resistance, the hot dip process creates a coating that's several times thicker and therefore more rugged than than lighter-duty styles.

Trawling Gear
Shackles
Boat Fittings

Information of Heavy Duty Wire Rope Thimble K2-B

BrandLG RIGGING®

Type

Type K2-B

Material

Superior Mild Steel

ProcessingStamping, Welding

Finish

Hot Dipped Galvanized / Electric Galvanized

Size

4", 4-1/2", 5", 5-1/2", 6", 7", 8", 9", 10", 11", 12", 14", 17", 19", 22", 24", 26"

Tips

With or without reinforcing plate, as per customer's requirement.

Note

NOT FOR LIFTING PURPOSES


Specifications of Heavy Duty Wire Rope Thimble K2-B

Specifications of Heavy Duty Wire Rope Thimble K2-B

Part No.

A
inch

B
mm

C
mm

D
mm

E
mm

F
mm

G
mm

Weight
kg/100

LGTK2B4

4″

75

50

50

17

22

6

40

LGTK2B4-1/2

4-1/2″

85

50

53

19

25

6

50

LGTK2B5

5″

100

60

60

21

29

8

80

LGTK2B5-1/2

5-1/2″

110

60

65

23

33

8

90

LGTK2B6

6″

115

70

70

25

34

8

100

LGTK2B7

7″

135

75

80

30

38

10

170

LGTK2B8

8″

155

80

100

33

44

10

250

LGTK2B9

9″

175

110

115

38

49

10

400

LGTK2B10

10″

190

120

120

41

52

15

450

LGTK2B11

11″

210

120

130

46

60

15

700

LGTK2B12

12″

245

140

145

52

65

15

830

LGTK2B14

14″

260

155

155

60

72

20

1250

LGTK2B17

17″

310

200

190

70

84

20

1800

LGTK2B19

19″

350

235

230

2

119

20

3050

LGTK2B22

22″

395

240

255

92

130

20

4050

LGTK2B24

24″

430

275

280

105

145

25

4950

LGTK2B26

26″

450

295

285

120

155

30

5400


Galvanized rope thimbles are designed for heavy duty jobs. If you need a light duty style, or a stainless steel fabrication, check out our other styles of thimbles for wire rope:

G-411 Standard Duty Galvanized Wire Rope Thimble
