Information of LGRIG® JIS 1168 Eye Bolt Forged Galvanized Carbon Steel

Brand	LGRIG®
Standard	Eye Bolt conformed To JIS 1168
Material	Carbon Steel
Processing	Drop Forged
Finish	Trivalent Chromate , Zinc plated , Hot dipped galvanized
Size	M8,M10,M12,M16,M20,M24,M30,M36,M42,M48,M64,M80,M90,M100
Usage	Lifting and connecting,Wire rope fittings,Chain fittings,Marine hardware fittings.
Country of Origin	China

Specifications of JIS 1168 Eye Bolt Forged Galvanized Carbon Steel

Part No.	Size	A	B	C	D	E	F	G	H	SWL(kg/KN)
Part No.	Size	A	B	C	D	E	F	G	H	Vertical		45°
LGJIS1168G08	M8	32.6	20	6.3	16	5	17	33.3	15	80	0.785	80	0.785
LGJIS1168G10	M10	41	25	8	20	7	21	41.5	18	150	1.47	150	1.47
LGJIS1168G12	M12	50	30	10	25	9	26	51	22	220	2.16	220	2.16
LGJIS1168G16	M16	60	35	12.5	30	11	30	60	27	450	4.41	450	4.41
LGJIS1168G20	M20	72	40	16	35	13	35	71	30	630	6.18	630	6.18
LGJIS1168G24	M24	90	50	20	45	18	45	90	38	950	9.32	950	9.32
LGJIS1168G30	M30	110	60	25	60	22	55	110	45	1500	14.7	1500	14.7
LGJIS1168G36	M36	133	70	31.5	70	26	65	131.5	55	2300	22.6	2300	22.6
LGJIS1168G42	M42	151	80	35.5	80	30	75	150.5	65	3400	33.3	3400	33.3
LGJIS1168G48	M48	170	90	40	90	35	85	170	70	4500	44.1	4500	44.1
LGJIS1168G61	M64	210	110	50	110	42	105	210	90	9000	88.3	9000	88.3
LGJIS1168G80	M80	266	140	63	130	50	130	263	105	15000	147	15000	147
LGJIS1168G90	M90	302	160	71	150	55	150	301	120	18000	177	18000	177
LGJIS1168G100	M100	340	180	80	170	60	165	335	130	20000	196	20000	196
