Name: LG Mooring Shackle Bolt Type Pin
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

 Screw Pin D Shackle U.S. Type

 Screw Pin Anchor Shackle U.S. Type

 Bolt Type Anchor Shackle U.S. Type

 Bolt Type Chain Shackle U.S. Type

 Nonrated Screw Pin Anchor Shackle U.S. Type

 Commercial Dee Shackle with Screw Pin European Type

 Commercial Bow Shackle with Screw Pin

 JIS Type Screw Pin D Commercial Shackle

 Grade S Bow Shackle Screw Pin AS2741

 Grade S Dee Shackle with Screw Pin AS2741

 AS2741 Grade S Bow Shackle with Safety Pin&Nut

 AS2741 Grade S Dee Shackle with Safety Pin & Nut

 LG Mooring Shackle Bolt Type Pin

 Grade 80 Alloy Bolt Type Anchor Shackle

 Grade 80 Alloy Bolt Type Chain Shackle

 Wide Body Sling Shackle Safety Pin Forged Alloy Steel

 Grade 80 Alloy Screw Pin Anchor Shackle

 Grade 80 Alloy Screw Pin Chain Shackle

 B.S.3032 Small Bow Shackle with Screw Collar Pin

 B.S.3032 Small Dee Shackle with Screw Collar Pin

 B.S.3032 Large Bow Shackle with Screw Collar Pin

 B.S.3032 Large Dee Shackle with Screw Collar Pin

 Shackles Similar to Din 82101 Form A/B/C Galvanised

 Italy Type Galvanized Bow Shackle

 Italy Type Galvanized Dee Shackle

 Round Pin Anchor Shackle U.S. Type

 Round Pin Chain Shackle U.S. Type

 Piling Shackle,long d shackle-LG RIGGING®

 Trawling Shackle D Type Blue Painted Square Head Pin of Lifting & Rigging Shackles

 Trawling Shackle Bow Type Square Head Pin Blue Painted of Lifting & Rigging Shackles

 Bow Shackle Square Head Pin High Tensile of Lifting & Rigging Shackles

 Dee Shackle Square Head Pin for Lifting and Rigging Shackles

 Bow Shackle Sunken Head of Lifting & Rigging Shackles

 Dee Shackle Sunken Head of Lifting & Rigging Shackles

 G80 Unilock Shackle Connecting Link LG RIGGING®

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of LG Mooring Shackle Bolt Type Pin

Material	Alloy Steel
Processing	Drop Forged
Finish	Hot dip galvanized Body / Powder Coated Pin
Size	28T, 40T, 60T, 90T, 150T

Specifications of LG Mooring Shackle Bolt Type Pin

Part No.	Description	Weight /kg	MBL[t]	e mm	a mm	c mm	d mm	d2 mm	d1 mm
LGMS0030	30T LG Mooring Shackle	1.38	30	58	44	100	20	47	22
LGMS0040	40T LG Mooring Shackle	2.06	40	68	52	125	22	50	25
LGMS0060	60T LG Mooring Shackle	3.76	60	89	62	150	28	58	28
LGMS0090	90T LG Mooring Shackle	5.74	90	98	84	170	32	72	34
