Information of Lifting Eye Nut DIN 582 UNC Thread Stainless Steel

Technical Notes	Eye Nut Conform To DIN582
Material	Stainless Steel (AISI 304 / AISI 316)
Processing	Precision Cast
Finish	Highly Polishing
Size	3/16″, 1/4″, 5/16”, 3/8″ , 1/2″, 5/8″, 3/4”, 1″, 1-3/16”, 1-7/16″ eye nut
Note	Never to be used for overhead lifting

Specifications of Lifting Eye Nut DIN 582 UNC Thread Stainless Steel

Part No.	D1	D3	H	Min.BL
Part No.	D1	D3	H	lbs
LG-SS-EN-582-UNC-3/16	3/16″	0.590″	0.984″	750
LG-SS-EN-582-UNC-1/4	1/4″	0.630″	1.102″	1370
LG-SS-EN-582-UNC-5/16	5/16”	0.787″	1.299″	1810
LG-SS-EN-582-UNC-3/8	3/8″	0.984″	1.654″	2980
LG-SS-EN-582-UNC-1/2	1/2″	1.181″	2.008″	4410
LG-SS-EN-582-UNC-5/8	5/8″	1.378″	2.362″	9100
LG-SS-EN-582-UNC-3/4	3/4”	1.575″	2.709″	15590
LG-SS-EN-582-UNC-1	1″	1.969″	3.417″	23380
LG-SS-EN-582-UNC-1-3/16	1-3/16”	2.362″	4.126″	41570
LG-SS-EN-582-UNC-1-7/16	1-7/16″	2.756″	4.827″	59760

The following guidelines of the Stainless Steel-Lifting eye nuts DIN 582 have to be observed in addition to the load values given in the above table.
The eye nut must be of fully screwd in to achieve a perfect contact between the two mating faces.
Both threads must be of a equal length and the base material of equal strength to that of the nut.
