Name: LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

 LGRIG® Collared Eyebolt BS 4278 Table 1 Metric

 LGRIG® Fork Head Clevis Joint DIN71752

 LGRIG® DIN580 Eye Bolt Galvanized

 LGRIG® DIN 582 Lifting Eye Nut

 LGRIG® Bow Nuts B.S. 3974 Metric Coarse & BSW Thread

 LGRIG® Long Shank Metric Collared Eye bolt BS4278 Table-1

 LGRIG® Collared Eyebolt With Oval Link Metric BS 4278 Table 2

 LGRIG® Dynamo Eyebolt with Enlarged Eye BS 4278 Table 3 Metric

 LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

 LGRIG® JIS 1168 Eye Bolt Forged Galvanized Carbon Steel

 LGRIG® JIS B 1169 Forged Eye Nut

 LGRIG® Forged Shoulder Machinery Eye Bolt LGS-279/LGM-279

 LGRIG® Forged Screw Eye Bolts LG-275

 LGRIG® Forged Shoulder Nut Eye Bolts LG-277

 LGRIG® Regular Nut Eye Bolts LG-291

 LGRIG® G-400 Eye Nut Galvanized UNC Threaded

 LGRIG® Rectangular Base Deck Eye Plates

 LGRIG® DIN 444 Swing Eye Bolt

 LGRIG® Wood Lag Screw w/Ring Thread Ring Bolt

 LGRIG® Welded Eye Bolt Wire Turned with Lock nut

 LGRIG® Unwelded Eye Bolt Wire Turned

 LGRIG® Lag Screw Eye Bolts Welded

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

Brand	LGRIG®
Technical Notes	Conform to B.S. 4278 – table 3 – 1984
Processing	Forged
Finish	Self-colored, Electro galvanised (zinc plated) available upon request
Size	8mm, 10mm, 12mm, 16mm, 20mm, 24mm
Safety Factor	5:1
Tips	Marked with size, WLL& CE.
Country of Origin	China

Specifications of LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

Specifications of Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

Part No.	Diameter Thread	Diameter Eye Inside	Diameter Eye	Length Base to Centre	Thread Length	Base Height	Diameter Base	Weight Each	Safe Working Load
	a	b	c	d	e	f	g	Weight Each	Safe Working Load
	mm							kgs	tonnes
LG4278L3M01	8	22	9.5	27	100	6	19	0.11	0.15
LG4278L3M02	10	22	9.5	27	100	6	19	0.12	0.25
LG4278L3M03	12	29	11	35	100	8	25	0.17	0.32
LG4278L3M04	16	32	13	41	114	9.5	29	0.35	0.63
LG4278L3M05	20	41	16	54	127	35	11	0.6	1.25
LG4278L3M06	24	51	19	64	127	13	41	1.1	2
