Name: Stainless Steel C Link LG RIGGING®
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Grade80 / Grade100 

Trawling Swivel 

Trawling Shackle 

Hooks / Links / Rope Fittings 

 Stainless Steel Eye Hoist Hook with Latch S-320 LG RIGGING®

 Stainless Steel Swivel Eye Hook with Latch for Trawling Gear LG RIGGING®

 Stainless Steel Rings Round O Ring for Trawling Gear LG RIGGING®

 Rings Stainless Steel Double Rings for Trawling Gear LG RIGGING®

 Stainless Steel Spectacles Rings For Trawling Net LG RIGGING®

 Stainless Steel Bow Rings for Trawling LG RIGGING®

 Stainless Steel C Link LG RIGGING®

 Split Link C Link Stainless Steel Casting LG RIGGING®

 Split Links Sister Clips Galvanized Steel LG RIGGING®

 Split Links Sister Clips Chrome Steel LG RIGGING®

 Rings Oval Stainless Steel LG RIGGING®

 Pear Rings Stainless Steel LG RIGGING®

 Stainless Steel Trawl G Hook Viking G Hook for Trawling Gear

 Stainless Steel Recessed Link LG RIGGING®

 Aluminium Ferrules DIN 3093(EN 13411-3) LG RIGGING®

 Copper Ferrule Oval Type for Trawling Gear

 O Ring Welded Steel LG RIGGING®

 Steel Oval Ring Welded LG RIGGING®

 Master Link Pear Shape Welded Steel LG RIGGING®

 Metal Washer Steel Washer LG RIGGING®

 Stainless Steel Commercial Turnbuckle European Type for Trawling Gear

 Stainless Steel Turnbuckle European Type Eye and Eye for Trawling Gear

 Stainless Steel Turnbuckle European Type Eye & Hook for Trawling Gear

 Stainless Steel Rigging Screw Jaw & Jaw for Trawling Gear

 Stainless Steel Rigging Screw Jaw to Swage Stud for Trawling LG RIGGING®

 Stainless Steel Swage Jaw Terminal for Trawling LG RIGGING®

 Stainless Steel Swage Eye Terminal for Trawling Gear

 Stainless Steel Swage Stud Terminal for Trawling Gear LG RIGGING®

 Stainless Steel Dome Head Terminal for Trawling Gear LG RIGGING®

 Spring Snap Hook DIN5299 Form C Stainless Steel for Trawling Gear

 Snap Hook DIN 5299 with Screw Nut Stainless Steel for Trawling Gear

 Carabine Hook with Spring Snap Stainless Steel for Trawling Gear LG RIGGING®

 Stainless Steel Eye Swivel Snap Shackle for Sailboat for Trawling Gear LG RIGGING®

 Stainless Steel Jaw Swivel Snap Shackle for Sailboat for Trawling Gear LG RIGGING®

 Stainless Steel Fixed Bail Snap Shackle for Trawling Gear LG RIGGING®

 Stainless Steel Wire Rope Clips DIN741 for Trawling Gear

 Stainless Steel Simplex Wire Rope Clip for Trawling Gear

 Stainless Steel Duplex Wire Rope Clip for Trawling Gear

 Stainless Steel Quick Links for Trawling Gear

 S Hooks Stainless Steel for Trawling Gear

 Lifting Eye Bolt DIN 580 UNC Thread Stainless Steel for Trawling Gear

 Lifting Eye Nut DIN 582 UNC Thread Stainless Steel for Trawling Gear

 Stainless Steel Long Shank Eye Bolt with Nut and Washer for Trawling Gear

 Stainless Steel U Bolt TPN Type with 2 Plates & Nuts for Trawling Gear

 Wire Rope Stop Sleeve for Trawling Gear

 Boss G Hook Stainless Steel for Trawling Gear

 Tension Lever with Chain and Hook Marine Lashing Equipment

Rope Thimbles 

Tools 

Trawling Chain 

Synthetic Rope 

Trawl Wire 

Fishing Net Float & Buoy 

Lifting Sling 

Trawl Block 

Wire / Chain Toggles 

Anchors & Fittings 

Dock Products 

Safety Appliance 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Informations of Stainless Steel C Link LG RIGGING®

Brand	LG RIGGING®
Material	Stainless Steel (AISI 304 / AISI 316)
Processing	Stamping (Wire forming)
Finish	Highly Polishing
Size	3/16", 1/4", 5/16", 3/8", 1/2", 5/8", 3/4", 7/8" 5mm, 6mm, 8mm, 10mm, 12mm, 16mm, 19mm, 22mm We can also customize it according to your requirement.

Specifications of Stainless Steel C Link LG RIGGING®


Part No.	Size	Dia. mm	MBL kN	A mm	B mm	Weight kg
LGSSCLW3/16"	3/16"	5	2.4	20	8	0.01
LGSSCLW1/4"	1/4"	6	3.5	24	9	0.02
LGSSCLW5/16"	5/16"	8	6.2	32	12	0.04
LGSSCLW3/8"	3/8"	10	9.7	40	15	0.08
LGSSCLW1/2"	1/2"	12	16.3	52	20	0.17
LGSSCLW5/8"	5/8"	16	24.7	64	24	0.32
LGSSCLW3/4"	3/4"	19	34.9	76	28	0.5
LGSSCLW7/8"	7/8"	22	41	88	33	0.75
LGSSCLW1"	1”	25	2.2T SWL	94	35	1.1
