 Stainless Steel Fixed Bail Snap Shackle

 Stainless Steel Eye Swivel Snap Shackle for Sailboat

 Stainless Steel Jaw Swivel Snap Shackle for Sailboat

 Key Pin Shackle Long D Shackle Stainless Steel

 Key Pin D Shackle with Bar Stainless Steel

 Oversized Bolt Type Pin Bow Shackle Precision Cast US Type Stainless Steel

 Oversized Screw Pin Anchor Shackle Precision Cast US Type Stainless Steel

 Strip D Shackle with Flat Pin Stainless Steel

Stainless Turnbuckle 

Stainless Eye Bolts & Nuts 

Stainless Thimbles 

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Information of Stainless Steel Chain Shackle Oversized Screw Pin

Technical Notes	D shackle conform to U.S. Federal Specification
Material	Stainless Steel AISI 304/316 D Shackle
Processing	Free Forging
Finish	Highly Polishing / Electrophoretic coating
Size	3/16”, 1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8”, 1-1/4”, 1-1/2”

Specifications of Stainless Steel Chain Shackle Oversized Screw Pin

Specifications of Stainless Steel Chain Shackle Oversized Screw Pin G-210

Part No.	D	d	a	C	Min.BL
Part No.	in				KN
LG-SS-210-S-3/16	3/16	1/4	0.38	0.71	13.7
LG-SS-210-S-1/4	1/4	5/16	0.47	0.88	24.4
LG-SS-210-S-5/16	5/16	3/8	0.53	1.03	38.2
LG-SS-210-S-3/8	3/8	7/16	0.66	1.25	54.9
LG-SS-210-S-7/16	7/16	1/2	0.75	1.44	54.9
LG-SS-210-S-1/2	1/2	5/8	0.81	1.63	97.7
LG-SS-210-S-5/8	5/8	3/4	1.06	2.00	152.6
LG-SS-210-S-3/4	3/4	7/8	1.25	2.38	184.7
LG-SS-210-S-7/8	7/8	1	1.44	2.81	219.7
LG-SS-210-S-1/1	1	1-1/8	1.69	3.19	278.1
LG-SS-210-S-1-1/8	1-1/8	1-1/4	1.81	3.58	390.7
LG-SS-210-S-1-1/4	1-1/4	1-3/8	2.03	3.94	494.4
LG-SS-210-S-1-1/2	1-1/2	1-5/8	2.38	4.81	672.9
