2 Inch Ratchet Straps w/Double J Hook-China LG Supply

2 Inch Ratchet Straps w/ Double J Hook-China LG Supply.

J-type hook end fittings are made of double wire to increase strength.

Our 2” Double J Hook Ratchet Straps are excellent tie down equipment if your anchor spot is narrow or shallow.

Also known as a 2″ double j hook, wire hooks offer an excellent combination of versatility and strength.

2” Double J Hook Ratchet Straps Tie Down are available in a wide range of lengths and colors.

The Main Advantage:


  • Industrial strength ratchet straps

  • Zinc plated welded wire hook

  • Long wide handled ratchet with zinc coating

  • Custom straps are available

Trawling Gear
Shackles
Boat Fittings

Information of 2 Inch Ratchet Straps w/Double J Hook-China LG Supply

Size

2″

Ratchet Handle/Hook

AL handle/Plastic handle/Double J Hook

Ratchet Hook Color

Yellow Zinc Plated

Webbing Material

Polyester

Webbing Color

Yellow/Orange/Blue

Webbing Length

27-30 Feet

Webbing Width

50 mm


Specifications of 2 Inch Ratchet Straps w/Double J Hook-China LG Supply

CODE NO.

SIZE(inch)

B.S.(kg/bs)

A(mm)

B(mm)

C(mm)

LGRH1001

4”

10000KG/22000LBS

*

*

*

LGRH7501

3”

10000KG/22000LBS

130

76

17

LGRH5001

2”

5000KG/11000LBS

105

52

12

LGRH5002

2”

5000KG/11000LBS

115

52

12

LGRH5003

2”

5000KG/11000LBS

85

52

15

LGRH5004

2”

3000KG/6600LBS

85

52

12

LGRH5005

2”

5000KG/11000LBS

130

52

12

LGRH5006

2”

3000KG/6600LBS

85

52

12

LGRH5007

2”

5000KG/11000LBS

106

52

12

LGRH5008

2”

400KG/11000LBS

85

52

11.5

LGRH3501

1.5”

3000KG/6600LBS

65

39

9

LGRH3502

1.5”

3000KG/6600LBS

86

39

9

LGRH3503

1.5”

3000KG/6600LBS

100

35

10

LGRH3504

1.5”

3000KG/6600LBS

65

39

9

LGRH3505

1.5”

2000KG/4400LBS

51

35

7

LGRH3506

1.5”

2000KG/4400LBS

82

32

7

LGRH2501

1  1/16

1500KG/3300LBS

53

27

7

LGRH2502

1  1/16

1500KG/3300LBS

85

27

7

LGRH2503

1  1/16

1500KG/3300LBS

60

27

7

LGRH2504

1”

1000KG/2200LBS

47

27

6.5

LGRH2505

1”

800KG/1760LBS

35

27

6.5

LGRH2506

1”

680KG/1500LBS

47

28

6.5

LGRH2507

1”

800KG/1760LBS

47

28

6


We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
