Name: End Shackle D-type Grade U2 & U3 LG RIGGING®
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Trawling Swivel 

Hooks 

Trawling Shackle 

Rope Thimbles 

Rings & Links 

Kelly's Eye & Stoppers 

G-Hooks & Recessed Links 

Connectors 

Tools 

Rockhopper Spare Parts 

Trawling Chain 

Synthetic Rope 

Trawl Wire 

Anchors & Fittings 

 Kenter Shackle Grade U2 & U3 LG RIGGING®

 End Shackle D-type Grade U2 & U3 LG RIGGING®

 D Type Joining Shackles Grade U2 & U3 LG RIGGING®

 Swivel Forerunner Grade U2 & 3 Anchor Chain Accessories LG RIGGING®

 Stainless Steel Delta Anchor DT Type LG RIGGING®

 Galvanised Plough/CQR Anchor LG RIGGING®

 Galvanised Folding Grapnel Anchor LG RIGGING®

 Galvanised Bruce/Claw Boat Anchor LG RIGGING®

 Galvanised Crown Stock Anchor Danforth Anchors LG RIGGING®

 Stainless Steel Folding Grapnel Anchor LG RIGGING®

 Stainless Steel Danforth Anchors Crown Stock Anchor LG RIGGING®

 Stainless Steel Four Prong Grapnel Anchor LG RIGGING®

 Stainless Steel Claw/Bruce Boat Anchor LG RIGGING®

Wire Rope Clips 

Ferrules & Terminals 

Rigging Screws 

Fishing Net Float 

Fenders & Buoys 

Lashing/Slings/Load Binders 

Trawl Blocks & Pulley 

Toggles & Spacers 

Safety Appliance 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Informations of End Shackle D-type Grade U2 & U3 LG RIGGING®

Brand	LG RIGGING®
Standard	ISO 1704
Material	Steel CM490/CM690
Surface Finish	Hot-dip galvanized \| Electro-galvanized \| Black Painting
Grade	U2 & U3
Function	Primary connection between: 1. Anchor crown shackle 2. Swivel forerunner assembly 3. Chain locker securing devices
Sizing	11-162mm nominal diameter (full dimensional compliance with DIN 6919)
QA Certificates	DNV/GL/ABS/BV/RINA/NK/KR/LRS/RS/IRS
Country of Origin	China

Specifications of End Shackle D-type Grade U2 & U3 LG RIGGING®

Part No.	Nominal DIA. mm d	Weight kg	Part No.	Nominal DIA. mm d	Weight kg	Part No.	Nominal DIA. mm d	Weight kg
LGAES011	11	1.18	LGAES050	50	45.20	LGAES100	100	353.00
LGAES012.5	12.5	1.34	LGAES052	52	50.90	LGAES102	102	378.00
LGAES014	14	1.50	LGAES054	54	53.80	LGAES105	105	385.00
LGAES016	16	1.52	LGAES056	56	63.00	LGAES107	107	420.00
LGAES017.5	17.5	2.05	LGAES058	58	70.00	LGAES111	111	463.00
LGAES019	19	2.41	LGAES060	60	77.50	LGAES114	114	485.00
LGAES020.5	20.5	3.25	LGAES062	62	86.30	LGAES117	117	528.00
LGAES022	22	3.95	LGAES064	64	96.30	LGAES120	120	570.00
LGAES024	24	5.12	LGAES066	66	99.60	LGAES122	122	602.00
LGAES026	26	6.70	LGAES068	68	102.60	LGAES124	124	632.00
LGAES028	28	8.10	LGAES070	70	126.20	LGAES127	127	679.00
LGAES030	30	10.00	LGAES073	73	138.20	LGAES130	130	729.00
LGAES032	32	11.77	LGAES076	76	146.00	LGAES132	132	762.00
LGAES034	34	14.20	LGAES078	78	164.00	LGAES137	137	852.00
LGAES036	36	16.55	LGAES081	81	190.00	LGAES142	142	949.00
LGAES038	38	19.55	LGAES084	84	212.00	LGAES147	147	1053.00
LGAES040	40	22.80	LGAES087	87	237.00	LGAES152	152	1164.00
LGAES042	42	26.00	LGAES090	90	245.00	LGAES157	157	1283.00
LGAES044	44	29.71	LGAES092	92	257.00	LGAES162	162	1410.00
LGAES044	46	34.30	LGAES095	95	300.00
LGAES048	48	38.00	LGAES097	97	335.00
