Captive Pin Bow Shackle Stainless Steel , also known as bow shackle captive pin.

Stainless steel captive pin commercial d shackle gets their name from the bow shape.

It's important to note that this shape dictates their use- they should only be used for straight line applications.

Our bow shackle stainless steel selection ranges in size from 4mm to 12mm.

Threaded shackle pin with key hole for tightening/loosening.

These stainless steel shackles wholesale, easily connect for temporary or permanent applications.


Trawling Gear
Shackles
Boat Fittings

Informations of Captive Pin Bow Shackle Stainless Steel



Brand

LG RIGGING®

Technical Notes

Stainless steel Bow shackle conform to European Type

Material

Stainless steel 304 or 316 bow shackle

Pin TypeCaptive Pin

Processing

Forged / Stamping

Finish

Highly Polishing / Electrophoretic Coating

Size

4mm, 5mm, 6mm, 8mm, 10mm, 12mm


Specifications of Captive Pin Bow Shackle Stainless Steel


Part No.

D
(mm)

A
(mm)

 L
(mm)

 R
(mm)

D1
(mm)

Min.BL

(KN)

LGSSBSCP04

4

8

16

14

35

52

LGSSBSCP05

5

10

20

17

44

82

LGSSBSCP06

6

12

24

21

53

119

LGSSBSCP08

8

16

32

28

71

213

LGSSBSCP10

10

20

40

35

89

336

LGSSBSCP12

12

24

48

42

108

494
