Name: LGRIG® DIN 582 Lifting Eye Nut
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

 LGRIG® Collared Eyebolt BS 4278 Table 1 Metric

 LGRIG® Fork Head Clevis Joint DIN71752

 LGRIG® DIN580 Eye Bolt Galvanized

 LGRIG® DIN 582 Lifting Eye Nut

 LGRIG® Bow Nuts B.S. 3974 Metric Coarse & BSW Thread

 LGRIG® Long Shank Metric Collared Eye bolt BS4278 Table-1

 LGRIG® Collared Eyebolt With Oval Link Metric BS 4278 Table 2

 LGRIG® Dynamo Eyebolt with Enlarged Eye BS 4278 Table 3 Metric

 LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

 LGRIG® JIS 1168 Eye Bolt Forged Galvanized Carbon Steel

 LGRIG® JIS B 1169 Forged Eye Nut

 LGRIG® Forged Shoulder Machinery Eye Bolt LGS-279/LGM-279

 LGRIG® Forged Screw Eye Bolts LG-275

 LGRIG® Forged Shoulder Nut Eye Bolts LG-277

 LGRIG® Regular Nut Eye Bolts LG-291

 LGRIG® G-400 Eye Nut Galvanized UNC Threaded

 LGRIG® Rectangular Base Deck Eye Plates

 LGRIG® DIN 444 Swing Eye Bolt

 LGRIG® Wood Lag Screw w/Ring Thread Ring Bolt

 LGRIG® Welded Eye Bolt Wire Turned with Lock nut

 LGRIG® Unwelded Eye Bolt Wire Turned

 LGRIG® Lag Screw Eye Bolts Welded

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® DIN 582 Lifting Eye Nut

Brand	LGRIG®
Standard	Conform to DIN582
Material	Superior Mild Steel
Processing	Drop Forged
Finish	Zinc plated, Hot dipped galvanized, Self-colored
Size	M6, M8, M10, M 12, M14, M16, M20, M22, M24, M27 M30, M33, M36, M39, M42, M45, M48, M52, M56, M64
Note	Never to be used for overhead lifting
Country of Origin	China

Specifications of LGRIG® DIN 582 Lifting Eye Nut

Specifications of DIN582 Lifting Eye Nut

Part No.	d1	d2	d3	d4	e	h	k	SWL	Weight Each
Part No.	mm							kgs
LG582EN06	M6	20	36	20	8.5	36	8	70	0.05
LG582EN08	M8	20	36	20	8,5	36	8	140	0.05
LG582EN10	M10	25	45	25	10	45	10	230	0.09
LG582EN12	M12	30	54	30	11	53	12	340	0.15
LG582EN14	M14	35	63	35	13	62	14	490	0.24
LG582EN16	M16	35	63	35	13	62	14	700	0.24
LG582EN20	M20	40	72	40	16	71	16	1200	0.36
LG582EN22	M22	45	81	45	18	81	18	1500	0.58
LG582EN24	M24	50	90	50	20	90	20	1800	0.72
LG582EN27	M27	50	90	50	20	90	20	2500	0.72
LG582EN30	M30	65	108	60	25	109	24	3200	1.32
LG582EN33	M33	65	108	60	25	109	24	4300	1.32
LG582EN36	M36	75	126	70	30	128	28	4600	2.08
LG582EN39	M39	75	126	70	30	128	28	6100	2.08
LG582EN42	M42	85	144	80	35	147	32	6300	3.11
LG582EN45	M45	85	144	80	35	147	32	8000	3.04
LG582EN48	M48	100	166	90	40	168	38	8600	5.02
LG582EN52	M52	100	166	90	40	168	38	9900	5.02
LG582EN56	M56	110	184	100	45	187	42	11500	6.69
LG582EN64	M64	120	206	110	50	208	48	16000	9.3
