Information of DIN764 Lifting Chain Stainless Steel Medium Link

Technical Notes	Stainless steel lifting chain Conform to DIN764
Material	Stainless Steel AISI304 or AISI316
Processing	Welded
Finish	High polished
Size	4mm, 5mm, 6mm, 8mm , 10mm , 13mm , 16mm, 18mm, 20mm
Tips	Perfect for use in exterior and corrosive environments.

Specifications of DIN764 Lifting Chain Stainless Steel Medium Link

Part No.	SIZE	INSIDE LENGTH	INSIDE WIDTH	OUTSIDE WIDTH	LENGTH PER 11 LINKS	WEIGHT/100M	BREAKING STRENGTH
Part No.	MM	MM	MM	MM	MM	KG	KN
LGSS764C01	4	16	5	14	176	31.3	7
LGSS764C02	5	18	7	18.2	198	51.4	11.8
LGSS764C03	6	21	8	21.5	231	74	16.5
LGSS764C04	8	28	11	29	308	131.5	32
LGSS764C05	10	35	14	36	385	200	50
LGSS764C06	13	45	18	47	495	350	80
LGSS764C07	16	56	22	58	616	520	125
LGSS764C08	18	63	24	65	693	650	160
LGSS764C09	20	70	27	72	770	820	200
