Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link LG RIGGING®, also known as Alloy Steel Chain/Fishery Chain Long Link, Mid Link, Short Link.

Fishing Link Chain Grade 80 Alloy Steel, used for commercial fishing, Not for lifting purposes.

Regular surface colors in yellow and black.

G80 fishing chain include short link chain, mid link chain, long link chain, you could choose according to your demand.

We can also make the non-standard trawling chain according to the clients requirements.

Pls find the specification for your reference.

Trawling Gear
Shackles
Boat Fittings

Information of Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link LG RIGGING®

BrandLG RIGGING®

Material

Superior Alloy Steel

Safety Factor

4: 1

Processing

Welded

Finish

Self colored+Polishing


Painted (Yellow or Black)

Size

Short link chain: 7*21mm, 10*30mm, 13*39mm, 16*48mm, 19*57mm, 20*60mm

Mid link chain: 10*40mm, 13*52mm, 14*50mm, 16*64mm, 19*76mm, 22*88mm, 26*92mm

Long link chain: 7*45mm, 9*53mm, 11*63mm, 13*80mm, 16*100mm, 19*100mm, 22*120mm, 28*150mm

Tips

Color Code: Customized according to customers' requirements


Specifications of Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link LG RIGGING®

Part No.

Kinds of Chain

Size
(MM)

Chain Diameter
(MM)

Width
(MM)

Weight
Kg/m

Breaking Load min
KN

Inside min

Outside max

8LGFCSL7×21

Short Link Fishing Chain

7*21

7.00

10

25.5

1.09

60.5

8LGFCSL10×30

10*30

10.00

14

36

2.2

126

8LGFCSL13×39

13*39

13.00

18.1

47.1

3.8

212

8LGFCSL16×48

16*48

16.00

22.4

57.4

5.63

320

8LGFCSL19×57

19*57

19.00

27.8

68.8

7.99

450

8LGFCSL20×60

20*60

20.00

29

72

8.85

510

8LGFCML10×40

Mid Link Fishing Chain

10*40

10.00

15

37

1.97

126

8LGFCML13×52

13*52

13.00

19.5

48.5

3.36

212

8LGFCML14×50

14*50

14.00

18.5

49.5

4.00

246

8LGFCML16×64

16*64

16.00

24

59

5.06

320

8LGFCML19×76

19*76

19.00

28.5

69.5

7.15

450

8LGFCML22×86

22*88

22.00

27

74

9.45

610

8LGFCML26×92

26*92

26.00

31

86

13.63

849

8LGFCLL7×45

Long Link Fishing Chain

7*45

7.00

10

25.5

0.83

60.5

8LGFCLL9×53

9*53

9.00

15

35

1.45

102

8LGFCLL11×63

11*63

11.00

18

43

2.16

151

8LGFCLL13×80

13*80

13.00

22

51

2.93

212

8LGFCLL16×100

16*100

16.00

26

61

4.42

320

8LGFCLL19×100

19*100

19.00

27

68

6.45

450

8LGFCLL22×120

22*120

22.00

32

84

8.74

610

8LGFCLL25x127

25*127

26.00

35

96

12

787

8LGFCLL28×150

28*150

28.00

44

103

14.3

984

8LGFCLL32x170

32*170

34.00

42

118

21

1286

Caution:

Do Not Use for Overhead Lifting. DO NOT EXCEED THE WORKING LOAD LIMIT.

WORKING LOAD LIMIT designates the maximum stress in pounds which should ever be applied to chain. This refers also to chain in the best condition, when new, and when the load is applied uniformly to a straight, untwisted length of chain.

WARNING: WORK LOAD LIMIT MUST NOT BE EXCEEDED

BREAK TEST LOAD is the minimum load in pounds at which new chain has been found by experience to break, under tests in which the load is applied in direct tension to a straight length of chain with a uniform rate of speed on a standard chain testing machine.

Bulk Photos of Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link LG RIGGING®

Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link LG RIGGING®
Fishing Chain Grade 80 Alloy Steel Long/Mid/Short Link LG RIGGING®
