Name: G100 Chain Connector European Type
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Grade80 / Grade100 

 SAFETY HOOKS BK EYE TYPE G100 WITH RECESSED TRIGGER LG RIGGING®

 Safety Hook Dacromet G80 LG RIGGING®

 Viking Master Link Recessed Link EVM LG RIGGING®

 G80 Viking Split Link Alloy Steel

 G80 Viking G Hook EVG Fishing & Trawling Gear LG RIGGING®

 G80 Viking G Hook EAG for Trawl and Fishing LG RIGGING®

 Viking G Hook ESG Type Alloy Forged for Trawl LG RIGGING®

 Viking G hook OFG Hook G80 Alloy Steel LG RIGGING®

 Viking G Hook EG Made of Cutting Steel Plate LG RIGGING®

 Viking Recessed Link EVR08/EVR10

 Viking Kelly's Eye EVR Ring 15T/20T LG RIGGING®

 G80 Kelly's Eyes Yellow Painted

 G80 Kelly's Eyes 8-Shaped Link for Fishing Alloy Steel LG RIGGING®

 Chain Connector TL with Smooth Pin G80 for Fishing/Trawl LG RIGGING®

 G80 Chain Connector European Type

 G80 Web Sling Connector B-Link LG RIGGING®

 Weldless Rings Forged Alloy Steel Yellow Painted Grade 80 LG RIGGING®

 G80 Master Link European Type EN1677-4/DIN5688-3

 G80 Master Link Assembly European Type EN1677-4 / DIN5688-3

 G80 Safety Hook with Swivel Eye (Improved)

 G80 Safety Hook Eye Self-locking Hook (Improved)

 G80 Safety Hook Clevis Self-Locking Hook (Improved)

 G80 Swivel Hoist Hook with Latch

 G80 Eye Sling Hook with Latch GS Type China LG RIGGING®

 G80 Eye Sling Hook with Safety Latch GH Type LG RIGGING®

 G80 Clevis Sling Hook with Latch

 Grade 80 Eye Grab Hook with Cradle

 Grade 80 Shortening Grab Hook Clevis

 Grade 80 Eye Grab Hook US Type

 Grade 80 Clevis Grab Hooks U.S. Type

 Grade 100 Master Link Forged Alloy

 Master Link Assembly Grade 100

 G100 Chain Connector European Type

 G100 Safety Hook Eye Self Locking Hook

 G100 Safety Hook Clevis Self Locking Hook

 Grade 100 Swivel Self Locking Hook Special Type

 G100 Cradle Eye Grab Hook

 G100 Cradle Clevis Grab Hook

 G100 Eye Foundry Hook

 Grade 80 Alloy Lifting Chains EN818-2

 Grade 100 Alloy Lifting Chain, EN818-2

 G80 Alloy Lifting Chain EN818-7

 Ratchet Binder G100 with Safety Hook

 Grade 80 Ratchet Load Binder Long Lever EN 12195-3

 Ratchet Load Binders Grade 70 US.Fed.Spec Grade Series

 Ratchet Load Binder with Eyes G70 US.Fed.Spec Grade Series

 Tension Lever with Chain and Hook Marine Lashing Equipment for Grade80 / Grade100

Trawling Swivel 

Trawling Shackle 

Hooks / Links / Rope Fittings 

Rope Thimbles 

Tools 

Trawling Chain 

Synthetic Rope 

Trawl Wire 

Fishing Net Float & Buoy 

Lifting Sling 

Trawl Block 

Wire / Chain Toggles 

Anchors & Fittings 

Dock Products 

Safety Appliance 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of G100 Connecting Link European Type

Brand	LG RIGGING^®
Technical Notes	G100 Connecting Link conform to European Type (EN1677)
Material	Forged Superior Alloy Steel
Safety Factor	Ultimate load is 4 times the Working Load Limit
Processing	Drop Forged+Quenched and Tempered Pressing flat only on request
Finish	Powder Coated
Size of Rope	6mm, 8mm, 10mm, 13mm, 16mm, 20mm, 22mm, 26mm, 32mm
Tips	Color Code: Customized according to customers' requirements Bigger Sub Link

Specifications of G100 Connecting Link European Type

Part No.	Weight (kg)	WLL (t)	B.L. (t)	H±1	A±1.5	K±2	L±2.5
10LGCLEU06	0.08	1.4	5.6	7.6	14	44.5	60
10LGCLEU08	0.18	2.5	10	10	18.5	61.5	84.5
10LGCLEU10	0.34	4	16	12.6	23	72	97.2
10LGCLEU13	0.68	6.7	26.8	16.8	27.5	89	127
10LGCLEU16	1.22	10	40	21	33.5	103	145
10LGCLEU20	2.13	16	64	24.5	42	116	175
10LGCLEU22	3	19	76	27	48	135	193
10LGCLEU26	5.15	26.5	106	32	61	164	228
10LGCLEU32	9.5	39.3	157.2	40	80	194	274
