LGRIG® Grade 100 Enlarged/Wider Master Link Assembly

LGRIG® Grade 100 Enlarged/Wider Master Link Assembly, also known as Grade 100 Master Link Sub-Assembly, Quad Master Link Assemblies, Master Link Multi, Master Link w/ Sub Assembly, Oblong Master Link Sub Assembly, Multi-leg master link.

Master Link Assemblies, engineered specifically for multi-leg sling assemblies, these Grade 100 Quad Master Links deliver heavy-duty connectivity for 3-leg and 4-leg chain slings while accommodating oversized crane hooks through extended internal dimensions.

Multi-leg master link, forged from quenched and tempered alloy steel with powder-coated corrosion protection, their reinforced construction features precision-flattened contact surfaces for seamless integration with omega links or thimbles.

Grade 100 Master Link Assemblies with Extra Large Sub-Links, Certified to EN 1677 standards with a 4:1 safety factor (MBL=4×WLL), these master links serve as critical junction points in lifting sling manufacturing—offering 25% greater strength-to-weight ratio than Grade 80 alternatives while enabling secure connections to non-standard anchor points.

Complementary to UMS/UMTS series configurations, their widened profile ensures reliable load distribution in overhead lifting operations across industrial rigging applications.

Get A Quote
Products
Trawling Gear
Trawling Swivel
Hooks
Trawling Shackle
Rope Thimbles
Rings & Links
Kelly's Eye & Stoppers
G-Hooks & Recessed Links
Connectors
Tools
Rockhopper Spare Parts
Trawling Chain
Synthetic Rope
Trawl Wire
Anchors & Fittings
Wire Rope Clips
Ferrules & Terminals
Rigging Screws
Fishing Net Float
Fenders & Buoys
Lashing/Slings/Load Binders
Trawl Blocks & Pulley
Toggles & Spacers
Safety Appliance
Lifting & Rigging
G100 Products
G100 Hooks
G100 Links, Rings
G80 Products
Turnbuckles
Shackles
Eye Bolts & Nuts
Rigging Hooks
Swivels
Forged Rings & Connector
Quick Links
Snap Hooks
Wire Rope
Wire Rope Thimbles
Wire Ropes Clips & Grips
Wire Rope Sleeves/Ferrules
Chains & Accessories
Chain Binders
Ratchet Straps
Lifting Sling of Lifting & Rigging
Lever Hoist
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Eye Plate
Stainless Steel Products
Shade Sail Hardware
Stainless Shackles
Stainless Turnbuckle
Stainless Eye Bolts & Nuts
Stainless Thimbles
Stainless Rings
Stainless Swivels
Stainless Quick Link
Stainless Wire Clips
Stainless Hooks & Clips
Stainless Terminals
Stainless U Bolts
Stainless Hinge
Stainless Pulleys
Drop Forged Stainless Products
Stainless Chains
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Latches
Mooring Compensators / Springs
Brake Lining
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture
Building Components
LGRIG® Lifting Clutch - Concrete Precast Element Lifting

Information of LGRIG® Grade 100 Enlarged/Wider Master Link Assembly

Standard

EN1677-4

Material

Super Alloy Steel

Safety Factor

Ultimate load is 4 times the Working Load Limit

Processing

Main Link: Forged

SubLink: Welded

Quenched and Tempered

Pressing flat only on request

Finish

Powder Coated

Size(Master link-Assembly)

19-14mm, 22-17mm, 30-22mm, 40-25mm, 50-32mm

Tips

Color Code : Customized according to customers' requirements


Specifications of LGRIG® Grade 100 Enlarged/Wider Master Link Assembly


Part No.

WEIGHT
(KG)

WLL
(T)

B.L
(T)

DIMENSION(MM)

A

B

D

a

b

d

10LGMLAOS06

1.8

3.5

14

150±5

90±4

19±1.5

120±5

70±4

14±1.5

10LGMLAOS08

3

5

20

160±5

95±4

22±1.5

140±5

80±4

17±1.5

10LGMLAOS10

6.5

11.5

46

200±5

120±5

30±1.5

160±5

95±4

22±1.5

10LGMLAOS13

15

17

68

250±6

150±5

40±2

190±5

110±5

25±1.5

10LGMLAOS16

23

28

112

300±6

200±5

50±2

200±5

120±5

32±2


Ultimate load is 4 times the Working Load Limit.

There will be pressing flat only on request for use with G100 Omega Link.


LGRIG® provide you High Strength Forged & Welded Alloy Steel Master Link for use in grade 80 & grade 100 chain slings. Perfect for a wide variety of lifting applications.

We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86 19524345486
E-mail:
Add:
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
Request a Free Quote
Upload
or drag files here.

Related G100 Links, Rings

LGRIG® Grade 100 Oversized Master Link
LGRIG® Grade 100 Oversized Master Link
LGRIG® Grade 100 Clevis Pear Link
LGRIG® Grade 100 Clevis Pear Link
LGRIG® Grade 100 Chain Rope Connector
LGRIG® Grade 100 Chain Rope Connector
LGRIG® Grade 100 Omega Link
LGRIG® Grade 100 Omega Link
LGRIG® Grade 100 Master Link Large Inside Length
LGRIG® Grade 100 Master Link Large Inside Length
China LG RIGGING's Updates
Exhibition in Norway 2024 LG RIGGING®
31
Jul
2025
Exhibition in Norway 2024 LG RIGGING® Learn More
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles
27
Jan
2025
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles Learn More
Introduction to Rigging Turnbuckles: Advantages and Applications
13
Jan
2025
Introduction to Rigging Turnbuckles: Advantages and Applications Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware Building Components
Resources
Video Blog FAQs About LG RIGGING® Document Download
About
Company News Industry News
Contact Us
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
sales@lg-lifting.com
+86 19524345486
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86 19524345486
