Name: LGRIG® Collared Eyebolt With Oval Link Metric BS 4278 Table 2
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

 LGRIG® Collared Eyebolt BS 4278 Table 1 Metric

 LGRIG® Fork Head Clevis Joint DIN71752

 LGRIG® DIN580 Eye Bolt Galvanized

 LGRIG® DIN 582 Lifting Eye Nut

 LGRIG® Bow Nuts B.S. 3974 Metric Coarse & BSW Thread

 LGRIG® Long Shank Metric Collared Eye bolt BS4278 Table-1

 LGRIG® Collared Eyebolt With Oval Link Metric BS 4278 Table 2

 LGRIG® Dynamo Eyebolt with Enlarged Eye BS 4278 Table 3 Metric

 LGRIG® Long Shank Metric Dynamo Eyebolts to BS 4278 Table 3

 LGRIG® JIS 1168 Eye Bolt Forged Galvanized Carbon Steel

 LGRIG® JIS B 1169 Forged Eye Nut

 LGRIG® Forged Shoulder Machinery Eye Bolt LGS-279/LGM-279

 LGRIG® Forged Screw Eye Bolts LG-275

 LGRIG® Forged Shoulder Nut Eye Bolts LG-277

 LGRIG® Regular Nut Eye Bolts LG-291

 LGRIG® G-400 Eye Nut Galvanized UNC Threaded

 LGRIG® Rectangular Base Deck Eye Plates

 LGRIG® DIN 444 Swing Eye Bolt

 LGRIG® Wood Lag Screw w/Ring Thread Ring Bolt

 LGRIG® Welded Eye Bolt Wire Turned with Lock nut

 LGRIG® Unwelded Eye Bolt Wire Turned

 LGRIG® Lag Screw Eye Bolts Welded

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Collared Eyebolt With Oval Link Metric BS 4278 Table 2

Brand	LGRIG®
Standard	BS4278 table 2 Forgings: 1984 c
Finish	Self coloured / Electric Galvanised / Hot Dip Galvanized
Size	M8, M10, M12, M14, M16, M18, M20, M22, M24, M30, M36, M42, M45, M48
Safety Factor	5:1
Country of Origin	China

Specifications of Oval Link Eyebolts to BS 4278 Table 2

Part No.	Size	S.W.L	Diameter Thread	Diameter Link	Link Inside Length	Link Inside Width	Base To Centre Height	Thread Length	Diameter Base	Weight Each
Part No.	Size	Tonnes	a (mm)	b (mm)	c (mm)	d (mm)	e (mm)	f (mm)	g (mm)	kg
LGBS4278T208	M8	0.1	8	13	53	24	20	27	39	0.33
LGBS4278T2010	M10	0.15	10	13	53	24	20	27	39	0.35
LGBS4278T212	M12	0.2	12	13	53	24	20	27	39	0.36
LGBS4278T214	M14	0.3	14	13	53	24	20	27	39	0.37
LGBS4278T216	M16	0.4	16	13	53	24	20	27	39	0.38
LGBS4278T218	M18	0.7	18	13	53	24	20	27	39	0.39
LGBS4278T220	M20	1	20	13	53	24	20	27	39	0.4
LGBS4278T222	M22	1.3	22	15	63	29	23	32	47	0.65
LGBS4278T224	M24	1.6	24	15	63	29	23	32	47	0.66
LGBS4278T230	M30	2.5	30	19	80	37	30	41	60	1.31
LGBS4278T236	M36	4	36	24	102	46	38	52	75	2.69
LGBS4278T242	M42	4.5	42	30	126	58	47	65	94	5.31
LGBS4278T245	M45	5	45	30	126	58	47	65	94	5.35
LGBS4278T248	M48	6.3	48	30	126	58	47	65	94	5.5
