Information of Oval Snap Hook w/Screw Nut

Material	Superior Mild Steel oval snap hook
Finish	Zinc Galvanized
Size	5x50mm, 6x60mm, 8x80mm, 10x100mm, 11x120mm
Tips	Use as fasteners or quick attachment.

Specifications of Oval Snap Hook w/Screw Nut

Part No.	Size	d	B	L	S	W.L.L.
Part No.	mm	mm	mm	mm	mm	lbs
LG-OSH-WS-01	5×50	5	25	50	9	100
LG-OSH-WS-02	6×60	6	30	60	11	140
LG-OSH-WS-03	8×80	8	40	80	13	250
LG-OSH-WS-04	10×100	10	50	100	16	400
LG-OSH-WS-05	11×120	11	58	120	21	500
