 Double Locking Snap Hook Electric Galvanized – LG RIGGING®

 Solid Brass Snap Hook Round Fixed Eye – LG RIGGING®

 Pear Shaped Spring Snap Hooks

 Zinc Plated S-Hook, Galvanized S Hook

 S Hook with Wire Latch

 Oval Snap Hook w/Screw Nut

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of Spring Snap Hook Galvanized DIN5299 Form C LG RIGGING®


Brand	LG RIGGING^®
Technical Notes	DIN5299 Form C Carbine Hook
Material	Low Carbon Steel Carabiner Hook
Processing	Stamping / Machining
Finish	Zinc Plated (Electro-galvnaized)
Size	4x40mm, 5x50mm, 6x60mm, 7x70mm, 8x80mm, 9x90mm, 10x100mm, 11x120mm, 12x140mm, 13x160mm, 14x180mm, 15x200mm spring snap hook
Tips	Not for overhead lifting
Packing	Cartons and then on Pallets (customization are available)

Specifications of Spring Snap Hook Galvanized DIN5299 Form C LG RIGGING®


Part No.	Size	A	B	C	D	L	W.L.L	N.W.
DIN 5299C	mm						lbs	kgs/100pcs
LGSPHC04	4X40	20	6	6	4	40	100	0.8
LGSPHC05	5×50	25	8	7	5	50	160	1.6
LGSPHC06	6×60	30	9	7	6	60	260	2.8
LGSPHC07	7×70	35	10	10	7	70	335	4.5
LGSPHC08	8×80	40	12	11	8	80	400	6.3
LGSPHC09	9×90	45	12	11	9	90	500	9
LGSPHC10	10×100	50	15	12	10	100	650	12.5
LGSPHC11	11×120	57	18	19	11	120	700	19.2
LGSPHC12	12×140	67	20	20	12	140	800	25
LGSPHC13	13×160	74	22	29	13	160	1300	35
LGSPHC14	14×180	86	22	42	14	180	1600	45.5
LGSPHC15	15X200	90	26	42	15	200	1800	61.8

LG RIGGING^®offers a wide variety of Regular Wire Hooks.

Carbine Hooks are also available in Stainless Steel Material, This type of finish is normally required for use by the food and beverage industry. It is also an excellent finish for use in applications with extreme exposure to dust, and chemicals environmental (such as salt water).
