Informations of Steel Wire Rope 6x19+IWRC Galvanized for Trawl LG RIGGING®

Brand	LG RIGGING^®
Construction	6×19+IWRC
Material	Galvanized Steel
Surface Finish	Electro-galvanized / Hot Dip Galvanized
Origin	China

Specifications of Steel Wire Rope 6x19+IWRC Galvanized for Trawl LG RIGGING®

Part No.	DIA (mm)	Minimum Breaking Load(Metric Ton)					Approx Weight Kg/m
Part No.	DIA (mm)	165Kg/mm² (1620N/mm²)		180Kg/mm² (1770N/mm²)		200Kg/mm² (1960N/mm²)	Approx Weight Kg/m
		FC	IWRC	FC	IWRC	IWRC	FC	IWRC
LGG619IWRC06	6	1.98	2.22	2.12	2.39	2.58	0.131	0.145
LGG619IWRC07	7	2.70	3.02	2.88	3.25	3.51	0.178	0.197
LGG619IWRC08	8	3.53	3.93	3.76	4.26	4.67	0.233	0.258
LGG619IWRC09	9	4.46	4.95	4.76	5.50	5.94	0.295	0.328
LGG619IWRC10	10	5.51	6.10	5.88	6.65	7.18	0.364	0.404
LGG619IWRC11	11	6.67	7.39	7.11	8.05	8.69	0.440	0.490
LGG619IWRC12	12	7.93	8.79	8.46	9.58	10.4	0.524	0.580
LGG619IWRC13	13	9.31	10.32	9.93	11.24	12.1	0.615	0.684
LGG619IWRC14	14	10.8	12.0	11.5	13.2	14.2	0.713	0.793
LGG619IWRC16	16	14.1	15.6	15.0	17.1	18.4	0.932	1.04
LGG619IWRC18	18	17.8	19.8	19.0	21.5	23.2	1.18	1.31
LGG619IWRC20	20	22.0	24.4	23.5	26.6	28.7	1.46	1.62
LGG619IWRC22	22	26.7	29.1	28.4	32.2	34.8	1.76	1.95
LGG619IWRC24	24	31.7	35.2	33.8	38.3	41.3	2.10	2.33
LGG619IWRC26	26	37.2	41.3	39.7	45.0	48.5	2.46	2.74
LGG619IWRC28	28	43.2	47.9	46.1	52.1	56.3	2.85	3.16
LGG619IWRC30	30	49.6	55.0	52.9	60.0	64.8	3.28	3.65
LGG619IWRC32	32	56.4	62.5	60.2	68.0	73.7	3.73	4.15
LGG619IWRC34	34	63.7	70.6	67.9	76.9	83.0	4.21	4.68
LGG619IWRC36	36	71.4	79.1	76.1	86.2	93.1	4.72	5.25
LGG619IWRC38	38	79.6	88.2	84.8	96.1	103	5.26	5.85
LGG619IWRC40	40	88.2	97.7	94.0	106.0	115	5.82	6.48
LGG619IWRC42	42	97.2	108.0	104.0	117.0	-	6.42	7.14
LGG619IWRC44	44	107.0	118.0	114.0	129.0	-	7.05	7.84
LGG619IWRC46	46	117.0	129.0	124.0	141.0	-	7.70	8.57
LGG619IWRC48	48	127.0	141.0	135.0	153.0	-	8.39	9.33
LGG619IWRC50	50	138.0	153.0	147.0	166.0	-	9.10	10.1
LGG619IWRC52	52	149.0	165.0	159.0	180.0	-	9.84	11.0
LGG619IWRC54	54	161.0	178.0	171.0	194.0	-	10.6	11.8
LGG619IWRC56	56	173.0	192.0	184.0	209.0	-	11.4	12.7
LGG619IWRC58	58	185.0	205.0	198.0	224.0	-	12.2	13.6
LGG619IWRC60	60	198.0	220.0	212.0	240.0	-	13.1	14.6
LGG619IWRC62	62	212.0	235.0	226.0	256.0	-	14.0	15.6
LGG619IWRC64	64	226.0	250.0	241.0	273.0	-	14.9	16.6
LGG619IWRC66	66	240.0	266.0	256.0	290.0	-	15.9	17.6
