Information of LGRIG® Swivel Eye Hoist Hook with Latch Grade 43 High Test

Brand	LGRIG®
Grade	Grade 43
Standard	Swivel Eye Hoist Hook with Latch Conform to U.S. Federal Specification
Material	Super Carbon Steel
Safety Factor	5:1
Processing	Body : Drop Forged / Quenched and Tempered Latch : Stamping
Surface Finished	Body : Powder Coated / Hot Dipped Galvanized / Zinc Plated / Self-Colored Latch : Dacromet / Stainless steel
Size	0.5Ton , 0.75Ton , 1Ton , 1.5Ton , 2Ton , 3Ton , 5Ton , 7.5Ton , 10Ton , 15Ton , 20Ton
Tips	Customized according to customers’ requirements
Country of Origin	China

Specifications of LGRIG® Swivel Eye Hoist Hook with Latch Grade 43 High Test


Part No.	Weight (KG)	Carbon steel		A±1 (mm)	E±2 (mm)	B±2 (mm)	H±0.6 (mm)	K±3 (mm)	L±3 (mm)	M±1 (mm)
Part No.	Weight (KG)	WLL(t)	B.L.(t)	A±1 (mm)	E±2 (mm)	B±2 (mm)	H±0.6 (mm)	K±3 (mm)	L±3 (mm)	M±1 (mm)
LG43SEHH01	0.3	0.5	2.5	31.5	17	22.5	9	110	137	15
LG43SEHH02	0.34	0.75	3.75	32	17	22.5	9	108.3	137	16
LG43SEHH03	0.57	1	5	37.5	22.5	29.5	12	133.5	163.5	16
LG43SEHH04	1.02	1.5	7.5	42.5	26	33	15.8	150.5	192	17.5
LG43SEHH05	1.24	2	10	42.5	26	33	15.8	163	209	23
LG43SEHH06	2.25	3	15	48	32.5	39	18	191	246	31
LG43SEHH07	4.66	5	25	64	43	53	25	243.5	313	34
LG43SEHH08	7.4	7.5	37.5	70	49.5	53	28.5	277	364	41.5
LG43SEHH09	10.6	10	50	79	54.5	62	32	332	431	55.7
LG43SEHH10	21.4	15	75	105	81	108	40	427	543	70
LG43SEHH11	32	20	100	105	100	96	40	465.3	596	76.2
