Name: Tubular Thimble G2 Type for Trawling and Fishing
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Grade80 / Grade100 

Trawling Swivel 

Trawling Shackle 

Hooks / Links / Rope Fittings 

Rope Thimbles 

 Tubular Thimble Galvanized without Gusset-LG Rigging®

 Tubular Thimble G2 Type for Trawling and Fishing

 Tubular-Tube Thimble Galvanized Super Big Size-LG Rigging®

 Tubular Thimble SCG Type-LG RIGGING®

 Tubular Thimble Stainless Steel for Trawling Gear

 Tube Thimble Cast Stainless Steel without Gusset for Trawling Gear

 Tubular Thimble Stainless Steel Light Duty for Trawling Gear

 Tubular Thimble Stainless Steel Heavy Duty for Trawling Gear

 Tubular Thimble Cast Stainless Steel with Gusset for Trawling Gear

 Tube Thimble Stainless Steel with Gusset for Trawling Gear

 Thimble Wire Rope G-414 Heavy Duty Stainless Steel for Trawling Gear

 Thimble Wire Rope G-411 Light Duty Stainless Steel for Trawling Gear

 Stainless Steel Wire Rope Thimble European Type for Trawling Gear

 Wire Rope Thimble Galvanized STG Type for Trawling Gear

 Tubular Thimble Galvanized SCMG Type for Trawling Gear

 Wire Rope Thimble European Commercial Type for Trawling Gear

 Wire Rope Thimble G414 Heavy Duty for Fishing Trawling Net

 G-411 Thimble Light Duty for Fishing Trawling Net

 Wire Rope Thimble DIN 6899 A Type Galvanized for Trawling Gear

 DIN 6899 B Type Wire Rope Thimble Galvanized for Fishing Trawling Net

 Wire Rope Thimble BS464 HDG EN13411-1 DIN3090 for Fishing Trawling Net

 Heavy Duty Thimble for Wire Rope K2-B for Fishing Trawling Net

 K2 Heavy Duty Stub-End Thimble

 K3 Fibre Rope Thimble

 Wire Rope Thimble K3-B with Ear&Master Link for Trawling Gear

 Galvanized Superloop Thimble Type K15

Trawling Chain 

Tools 

Synthetic Rope 

Lifting Sling 

Trawl Block 

Fishing Net Float & Buoy 

Wire / Chain Toggles 

Anchors & Fittings 

Dock Products 

Safety Appliance 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of Tubular Thimble G2 Type for Trawling and Fishing

Material	Superior Mild Steel
Processing	Machining / Stamping
Finish	Zinc Plated and then Powder Coated, Hot Dip Galvanized
Size-Wire	10mm, 12mm, 15mm, 17mm, 19mm, 22mm, 25mm, 28mm, 30mm, 35mm, 40mm, 45mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 88mm, 94mm, 107mm, 112mm, 120mm,127mm, 140m
Tips	Supplied in open finish or with welded gusset plate

Specifications of Tubular Thimble G2 Type for Trawling and Fishing

Part No.	A	B	C	D	E	Weight	For wire max.
Part No.	mm					kg	mm
LGTTbFG215	15	109	27	5.0	10	0.42	12
LGTTbFG217	17	115	27	5.0	10	0.50	14
LGTTbFG219	19	125	32	5.0	12	0.56	16
LGTTbFG222	22	140	35	5.0	15	0.67	18
LGTTbFG225	25	158	45	6.3	16	1.3	22
LGTTbFG228	28	176	45	7.0	16	1.62	24
LGTTbFG230	30	195	47	7.0	18	2.05	26
LGTTbFG235	35	210	60	7.0	22	2.55	32
