Information of Wood Screw Lag Thread Ring Bolt

Steel construction.
Zinc plated finish.
Lag thread on screw eye.
Sharp screw point bites into wood easily and quickly.
Ring Bolts are Welded and NOT TO BE USED FOR LIFTING APPLICATIONS.

Available Size for Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread:

1/4″ x 2″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

5/16″ x 2-1/4″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

3/8″ x 2-1/2″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

1/2″ x 3-1/4″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

5/8″ x 4-1/2″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

3/4″ x 4-1/2″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

7/8″ x 5″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread;

1″ x 6″ Wood Screw Lag Thread Ring Bolt, Ring Bolts Screw Thread.

Specifications of Wood Screw Lag Thread Ring Bolt

No.	Diameter (A) & Shank Length (B)	O.D. Eye of Bolt (C)	I.D. Eye of Bolt (D)	I.D. Eye of Ring	Overall Length (E)	Thread Length (T)	Wt. per 100 pcs (lbs)
LGRBST101	1/4″ x 2″	1″	1/2″	1-3/4″	4-3/4″	1-1/2″	16.7
LGRBST102	5/16″ x 2-1/4″	1-1/4″	5/8″	2″	5-1/2″	1-5/8″	25.9
LGRBST103	3/8″ x 2-1/2″	1-1/2″	3/4″	2-1/2″	6-1/2″	1-3/4″	44.3
LGRBST104	1/2″ x 3-1/4″	2″	1″	3″	8-1/4″	2-1/8″	100.7
LGRBST105	5/8″ x 4-1/2″	2-5/16″	1-1/4″	2-3/4″	9-9/16″	2-1/2″	162
LGRBST106	3/4″ x 4-1/2″	2-3/4″	1-1/2″	3″	10-1/4″	3″	253
LGRBST107	7/8″ x 5″	3-1/4″	1-3/4″	3-1/4″	11-1/2″	3-1/4″	403
LGRBST108	1″ x 6″	3-3/4″	2″	3-3/4″	13-1/2″	3-1/2″	599
