Name: LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Stainless Marine Hinges 

Bimini Top Fittings 

Cleats & Fairleads 

Angle Bracket 

Rail Fittings 

Thru-Hull & Deck Fittings 

 Stainless Steel Low Profile Thru Hull Fitting Hose Connection-China

 Stainless Steel Tank Vent 90 Degree-China LG Supply

 Stainless Steel Deck Fill 45 Degree-LG RIGGING®

 Stainless Steel Deck Filler-China LG Manufacture

 LGRIG® Stainless Steel Marine Deck Fill with Key

 LGRIG® 316 Stainless Steel Deck Fill with Keyless Cap

 LGRIG® 316 Stainless Steel 45°Angled Deck Fill with Key

 LGRIG® 316 Stainless Steel 45°Angled Keyless Deck Fill

 LGRIG® Nylon Fuel Deck Fill with Keyless Cap

 LGRIG® Nylon Deck Fill with Keyless Cap –Water

 LGRIG® Nylon Thru-Hull Fitting with Hose Barb - Skin Fitting

 LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim

 LGRIG® Stainless Steel Marine Deck Drain Scupper

 LGRIG® Stainless Steel Straight Thru-Hull Exhaust Skin Fitting

 LGRIG® Stainless Steel Angled Exhaust Skin Fitting

Stainless Latches 

Mooring Compensators / Springs 

Brake Lining 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim

Brand	LGRIG®
Product Name	Stainless Steel/Nylon Straight Thru-Hull Fitting with Barb
Alternative Name	Nylon Straight Skin Fitting with Stainless Steel Trim
Product Type	Straight Thru-Hull / Skin Fitting
Body Material	Nylon
Trim Material	Stainless Steel
Construction	Stainless Steel Trim + Nylon Body
Surface	Smooth Nylon Surface with Stainless Steel Trim
Configuration	Straight
Connection Type	Hose Barb / Barb Tail
Installation Type	Through-Hull
Size Range	5/8"–2"
Features	Lightweight, Durable, Corrosion Resistant, Straight Design, Stainless Steel Trim
Use	Hose Connection, Drainage, Fluid Discharge
Applications	Boat Drain, Sink Drain, Cockpit Drainage, Bilge Pump Discharge, Livewell Drainage, Marine Plumbing
Suitable For	Boats, Yachts and Marine Plumbing Systems
Country of Origin	China

Specification of LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim


Part No.	SIZE	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	F (mm)	WT (KG)
LGSSTHFNST16	5/8"	65	33	15	23	16	10.5	0.026
LGSSTHFNST20	3/4"	74.5	39	18	26.5	19	12	0.033
LGSSTHFNST25	1"	85.5	48	24	33	25	17	0.063
LGSSTHFNST32	1 1/4"	99	60	33	42	32	23	0.099
LGSSTHFNST38	1 1/2"	106	70	37.5	48	38	28.5	0.111
LGSSTHFNST50	2"	126	86	48	60	50	41	0.18
