Name: LGRIG® Wing Fenders
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Trawling Swivel 

Hooks 

Trawling Shackle 

Rope Thimbles 

Rings & Links 

Kelly's Eye & Stoppers 

G-Hooks & Recessed Links 

Connectors 

Tools 

Rockhopper Spare Parts 

Trawling Chain 

Synthetic Rope 

Trawl Wire 

Anchors & Fittings 

Wire Rope Clips 

Ferrules & Terminals 

Rigging Screws 

Fishing Net Float 

Fenders & Buoys 

 LGRIG® Square Fenders

 LGRIG® D Type Fenders

 Rubber to Metal Bonded-Customized Products

 Rubber Molded Dock Fenders

 Arch Fenders-China LG Supply

 Vehicle Wheel Chocks

 Laminated Wheel Chocks

 Molded Dock Bumpers

 Rubber Laminated Dock Bumpers

 LGRIG® Super Cell Rubber Fenders SCA Type

 LGRIG® Super Cone Fenders SCB Type

 LGRIG® Arch Fenders DA Type

 LGRIG® Arch Fenders DAF Type

 LGRIG® Rubber Ladder Fender Arch Type

 LGRIG® Corner Arch Fenders

 LGRIG® Cylindrical Fender CYL Type

 LGRIG® Tug Cylindrical Fender TY Type

 LGRIG® W Fenders

 LGRIG® M Fender

 LGRIG® Wing Fenders

 LGRIG® Leg Fenders Element Fenders

 LGRIG® Marine Ladders Rubber

 LGRIG® Foam Fenders PF Type

Lashing/Slings/Load Binders 

Trawl Blocks & Pulley 

Toggles & Spacers 

Safety Appliance 

Footrope Gear 

Trawl Door 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Specification of LGRIG® Wing Fenders

Part No.	Specification	H	W	B	D	P	Q	G	M	Weight(kg)
LGWF280540	DR 280×540	280	540	430	40	41	82	165	120	125
LGWF300540	DR 300×540	300	540	430	40	41	82	165	120	130
LGWF300600	DR 300×600	300	600	490	40	41	82	165	120	144

Specification	280×540300×540300×600
L	1000	1500	2000	2500	3000
n	2	3	4	4	5
E	700	600	570	550	540
K	150	150	145	150	150

Units:mm

Performance of LGRIG® Wing Fenders

Specification		280H	300H
Performance
Rated Deflection:50%	R(kN)	375	495
	E(kNm)	14	20

R:Reaction Force, E:Energy Absorption.

Rated Deflection: 50%

Performance tolerance: ±10%

The performance mentioned above is the performance for per meter length fender, Dynamic performance in different length shall be calculated by times the multiple of 1000mm length.
